Servicing DIMMs 71
Servicing DIMMs
DIMMs are cold-service components that can be replaced after you remove the processor
module from the system. For the location of DIMMs, see “DIMM Locations” on page 16.
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. This discharge can cause server components to fail.
These topics describe service procedures for the DIMMs in the server.
Step Description Links
1. Understand how to configure the
DIMMs.
“DIMM Configuration” on page 71
2. Locate a faulty DIMM. ■ “Determine Which DIMM Is Faulty (FMA)” on page 73
■ “Determine Which DIMM Is Faulty (LEDs)” on page 75
■ “DIMM Configuration Fault Messages” on page 76
3. Replace a DIMM. ■ “Remove a DIMM or DIMM Filler Panel” on page 76
■ “Install a DIMM” on page 78
■ “Verify the DIMM” on page 80
Related Information
■
“Identifying Components”
■
“Detecting and Managing Faults”
■
“Preparing for Service”
■
“Component Service Task Reference” on page 23
■
“Returning the Server to Operation”
DIMM Configuration
