Orban Optimod-AM 9200 User Manual

OPTIMOD-AM 9200 VERSION 3.0 SOFTWARE ADDENDUM
A-11
Appendix 2: 9200 User Preset Settings Sheet
Parameter Labels Units Your Settings Range (CCW to CW)
LESS-MORE CONTROL
LESS-MORE 1.0 … 10.0
BASIC EQ
LF GAIN dB -10.0 … +10.0
MF GAIN dB -10.0 … +10.0
HF CURVE NRSC, 0 … 10
HF GAIN dB 0 … 22
EXPERT EQ: LF EQ
DJ BASS off, on
LF FREQ Hz 50 … 250
LF WIDTH oct 0.8, 0.9, 1.0, 1.1, 1.2, 1.3,
1.4, 1.5, 1.7, 1.9, 2.0, 2.2,
2.4, 2.6, 2.8, 3.0, 3.3, 3.5,
3.7, 4.0
LF GAIN dB -10.0 … +10.0
EXPERT EQ: MF EQ
MID BASS dB 0 … +12
MF FREQ Hz 250 … 4,000
MF WIDTH oct 0.8, 0.9, 1.0, 1.1, 1.2, 1.3,
1.4, 1.5, 1.7, 1.9, 2.0, 2.2,
2.4, 2.6, 2.8, 3.0, 3.3, 3.5,
3.7, 4.0
MF GAIN dB -10.0 … +10.0
EXPERT EQ: HF EQ
HF CURVE 0 … 10, NRSC
HF GAIN dB 0 … 22
EXPERT EQ: SYSTEM BANDWIDTH
HI PASS Hz 50 … 100
LO PASS kHz 4.5 … 9.0, NRSC
FULL CONTROL PARAMETERS: screen 1
AGC off, on
AGC DRIVE -10 … +25
AGC REL dB/S 0.5, 1.0, 1.5, 2 … 20
GATE THR dB off, -44 … -15
