Orban Optimod-AM 9200 User Manual

A-12
OPTIMOD-AM 9200 VERSION 3.0 SOFTWARE ADDENDUM
Parameter Labels Units Your Settings Range (CCW to CW)
FULL CONTROL PARAMETERS: screen 2
BASS COUPL % 0 … 100
MB DRIVE 0 .. 25
MB RELEASE slow, mslow, mfast, fast
MB CLIP -4.0 .. +5.0
FULL CONTROL PARAMETERS: screen 3
DWNEXP THR dB off, -6.0 … +12.0
HF CLIP dB 0.0 … +6.0
B1/B2 XO Hz 150, 200
EXPERT CONTROL: 5B INPUT DRIVE screen 1
B1 DRIVE dB -3.0 … +3.0
B2 DRIVE dB -3.0 … +3.0
B3 DRIVE dB -3.0 … +3.0
B4 DRIVE dB -3.0 … +3.0
EXPERT CONTROL: 5B INPUT DRIVE screen 2
B2 DRIVE dB -3.0 … +3.0
B3 DRIVE dB -3.0 … +3.0
B4 DRIVE dB -3.0 … +3.0
B5 DRIVE dB -3.0 … +3.0
EXPERT CONTROL: OUTPUT MIX screen 1
B1 OUT dB -3.0 … +3.0
B2 OUT dB -3.0 … +3.0
B3 OUT dB -3.0 … +3.0
B4 OUT dB -3.0 … +3.0
EXPERT CONTROL: OUTPUT MIX screen 2
B2 OUT dB -3.0 … +3.0
B3 OUT dB -3.0 … +3.0
B4 OUT dB -3.0 … +3.0
B5 OUT dB -3.0 … +3.0
EXPERT CONTROL: FINAL CLIP
FINAL CLIP 0.0 … +5.0
