LO
W ANGLE NOZZLES
Nozzle
Pressure
PSI
Radius
ft.
Flow
GPM
Precip in/hr.
L1
30 21 1.2 0.52 0.61
40 24 1.4 0.47 0.54
50 26 1.7 0.48 0.56
60 28 1.8 0.44 0.51
L2
30 28 1.8 0.44 0.51
40 32 2.1 0.39 0.46
50 34 2.4 0.40 0.46
60 36 2.5 0.37 0.43
L3
30 33 2.9 0.51 0.59
40 37 3.4 0.48 0.55
50 39 3.9 0.49 0.57
60 40 4.1 0.49 0.57
L4
30 32 3.8 0.71 0.83
40 35 4.4 0.69 0.80
50 37 5.0 0.70 0.81
60 39 5.4 0.68 0.79
STANDARD NOZZLES
Nozzle
Pressure
PSI
Radius
ft.
Flow
GPM
Precip in/hr.
1
30 27 0.8 0.21 0.24
40 28 1.1 0.27 0.31
50 29 1.2 0.27 0.32
60 29 1.3 0.30 0.34
2
30 35 1.5 0.24 0.27
40 38 1.7 0.23 0.26
50 38 2.0 0.27 0.31
60 39 2.1 0.27 0.31
4
30 39 3.4 0.43 0.50
40 42 3.9 0.43 0.49
50 44 4.5 0.45 0.52
60 44 4.8 0.48 0.55
7
Preinstalled
30 36 2.6 0.19 0.20
40 40 3.0 0.18 0.21
50 42 3.4 0.19 0.21
60 42 3.7 0.20 0.23
8
30 48 7.7 0.64 0.74
40 50 9.0 0.69 0.80
50 52 9.8 0.70 0.81
60 55 10.0 0.64 0.74
n s
n s
Note: All
precipitation rates
calculated for 180
degree operation.
For the precipitation
rate for a 360
degree sprinkler,
divide by 2.
n Denotes square
spacing.
s Denotes
equilateral
triangular spacing.
Data represent test
results in zero wind.
Adjust for local
conditions.
Radius can be
reduced by up to
30% with nozzle
retaining screw.
(This may alter the
uniformity of the
spray pattern.)
