VIDEO
Screen Size 20” 26” 32”
Max. Resolution 640 x 480 @ 75Hz 1366 x 768 @ 60Hz 1366 x 768 @ 60Hz
Pixel Pitch 0.6375 x 0.6375mm 0.4215 x 0.4215mm 0.51 x 0.51mm
Brightness 450 cd/㎡ 450 cd/㎡ 500 cd/㎡
Contrast Ratio 400 : 1 300 : 1 1200 : 1
Aspect Ratio 4:3 16:9 16:9
Viewing Angle (H/V) 170° / 170° 178° / 178° 178° / 178°
Display Color 16.2 Million 16.7 Million 16.7 Million
Response Time < 30ms < 8ms < 8ms
Video System NTSC / PAL / SECAM NTSC / PAL / SECAM NTSC / PAL / SECAM
Frequency (H) 31 ~ 48KHz 30 ~ 64KHz 30 ~ 64KHz
Frequency (V) 56 ~ 75Hz 56 ~ 75Hz 56 ~ 75Hz
Panel Lamp Life 50,000 hours 50,000 hours 50,000 hours
INTERFACE
BNC In /Out 1 / 2 2 / 3 2 / 3
S-Video In / Out 1 / 1 1 / 1 1 / 1
VGA In (15Pin D-Sub) 0 1 1
Camera Out 1 1 1
DVI-D In / HDMI In 0 / 0 1 / 1 1 / 1
Audio In (RCA Type) 1 3 3
PC Stereo In 0 / 0 1 / 1 1 / 1
Remote Control Yes
AUDIO
Built-In Speaker Yes (2W x 2) Yes (4W x 2) Yes (4W x 2)
FEATURES
Filter Type 3D Comb Filter / De-Interlace
LCD Protective Shield Yes
Multi Language English, Spanish, French English, Spanish, French, German, Italian
Motion Detection Microwave Motion Sensor (10~30 feet)
Pop up Image Upon Motion Detection or Sleep Mode
CAMERA
Camera Type WDR Camera WDR Camera WDR Camera
Mechanical Design Tilt Swivel Camera
Signal / Scanning System NTSC PAL
Image Sensor 1/3" SONY Super HAD CCD
Resolution Horizontal : 540 TV Lines
Lens Mount 4~9mm Vari-focal Lens(F=1.5)
Sensitivity 0.1 Lux (Normal Mode) / 0.001 Lux (DSS Mode)
Electronic Shutter 1/60 ~ 1/10,000 Sec 1/50 ~ 1/10,000 Sec
CABINET
Material / Color Powder Coat Metal / Black (White Optional)
DIMENSION
Outline Dimension 18.93" x 18.01" x 3.0" 25.9" x 18.3" x 4.9" 31.2" x 21.4" x 5.4"
POWER
Consumption : < On < 60W < 120W < 150W
Electrical Ratings
AC100 ~ 240V or DC 12V or DC 24V AC100 ~ 240V or DC 24V
2.1 Specifications (General)
NOTE : Technical specifications are subject to change without notice..
