© 2008 directed electronics—all rights reserved 13
SPECIFICATIONS
Amplifi er Section CO6004
Power Output in Watts RMS, 4 Ohms 60 x 4
Power Output in Watts RMS, 2 Ohms 75 x 4
Distortion at Rated Power < 0.9% THD+N
Frequency Response 20Hz to 30kHz
+/- 0.5 dB
Linear Bandwidth 20Hz to 20kHz
±3dB
Damping Factor > 100
Input Sensitivity 250 mV - 8V
Input Impedance > 10k
Fuse Type (2) 25 Amp ATC
Dimensions 2.1" x 8.1" x 13.4"
Weight 7.3 lbs.
Crossover Section
Low Pass and Hi-Pass Crossover Continuously variable/
2nd Order
Low Pass Frequency Range 50Hz to 500Hz
Continuous 2 load 20Hz to 200Hz, < 0.1% THD, with input voltage at 13.8VDC.
