OWC ENVOY PRO EX User Manual

OWC Envoy Pro EX with USB-C Device Setup
2
2. Remove the enclosure from the foam bag, turn the
enclosure over then remove the two screws secured at
opposite corners. Set the screws aside.
DEVICE SETUP
2.1 Drive Assembly
1. Remove the enclosure (in the protective foam bag)
and the screw packet from the box. The packet
should contain two drive enclosure screws, one
drive mount screw, and two rubber feet.
4. Set the top portion of the enclosure on a static-free work
surface, face up, then align the M.2 SSD connector with
the black PCIe connector on the Envoy Pro’s circuit
board. Carefully seat the drive into the connector.
3. Remove the bottom cover. Note that the
underside has a thermal pad; the orientation of
the cover will be important later.
5. Using the shorter drive mount screw from the
packet, carefully secure the M.2 SSD to the
drive post.

OWC ENVOY PRO EX Specifications

General

NVMe	Yes
Interface	PCI Express 3.0
Read speed	1250 MB/s
Write speed	- MB/s
SSD capacity	8000 GB
SSD form factor	M.2
Wi-Fi	-
USB version	3.2 Gen 2 (3.1 Gen 2)
USB connector	USB Type-C
Data transfer rate	10 Gbit/s
Thunderbolt version	3
Certification	FCC
Product color	Silver
Housing material	Aluminum
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Windows operating systems supported	Windows 10
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Sustainability certificates	RoHS

Weight and Dimensions

Depth	115 mm
Width	65 mm
Height	9 mm
Weight	148 g
