P.Lindberg PA600D User Manual

4 MAN 9029898 EN V1
P. Lindberg A/S Sdr. Ringvej 1 www.p-lindberg.dk
Tel.: +45 70212626 6600 Vejen, Denmark E-mail: salg@p-lindberg.dk
Specifications
*Slow wire speed is when the pulley with hook is fitted
Fitting/setting up
The electric hoist is supplied with fittings that can be used to mount it on a steel beam
(square/rectangular tube). NB: The tube dimension and strength must match the
electric hoist’s lifting force. The fittings and setting up must be carried out in
collaboration with qualified personnel who can guarantee that the electric hoist is
fitted correctly and safely.
125/250 kg
300/600 kg
500/1000 kg
Electric power
connection
230 V
230 V
230 V
Power consumption 2.2 A 4.6 A 7.4 A
Wire diameter
3.0 mm
4.5 mm
5.6 mm
Wire breaking strength
1870 N/mm²
1770 N/mm²
1770 N/mm²
Power
500 W
1050 W
1600 W
Weight
10 kg
17.5 kg
33 kg
Ingress protection
rating
IP54
IP54
IP54
Lifting height,
single/double wire
6/12 m
6/12 m
6/12 m
Lifting capacity,
single/double wire
125/250 kg
300/600 kg
500/999 kg
Cable speed,
single/double wire*
8/4 m/minute
8/4 m/minute
8/4 m/minute
