Panasonic CF-29 Series User Manual

43
Appendix
Specifications
Model No.
CPU
Memory
Video Memory
LCD Type
Displayed Colors*
3
External Display
Hard Disk Drive
Keyboard
Floppy Disk Drive
PC Card Slot
Allowable current
(total for two slots)
RAM Module Slot*
6
SD Memory Card Slot*
7
Interface Parallel Port
External Display Port
Serial Port
Microphone Jack*
8
Headphone Jack
Expansion Bus Connector
USB Port
Modem
LAN
Wireless LAN
External Antenna Connector
Pointing Device
Sound
*
1
1 MB = 1,048,576 bytes
*
2
A segment of the main memory is allotted automatically depending on the computer’s operating status. The size of the Video Memory
cannot be set by the user.
*
3
A 16,777,216 color display is achieved by using the dithering function.
*
4
Maximum resolution depends on the specifications of the external display.
*
5
1GB = 1,000,000,000 bytes. Your operating system or some application software will report as fewer GB.
*
6
Only a RAM module designed for PC2-3200 can be added.
*
7
This slot does not support the MultiMedia card.
Operation has been confirmed for Panasonic SD Memory Cards with up to 1 GB capacity.
*
8
Use only a monaural condenser microphone.
*
9
The settings for the K56flex modem need to be changed according to the AT command.
Main Specifications
CF-29LTQGZBE/CF-29LTQGZL2 CF-29L3QGZBE/CF-29L3QGZL2
Intel
®
Pentium
®
M Processor Low Voltage 778 (1.60 GHz, 2 MB*
1
L2 cache, 400 MHz FSB)
512 MB*
1
(1536 MB*
1
Max.)
UMA (128 MB*
1
Max.)*
2
13.3 XGA type (TFT) with Touchscreen 13.3 XGA type (TFT)
65,536/16,777,216 colors (800 x 600 dots/1024 x 768 dots)
65,536/16,777,216 colors (800 x 600 dots/1024 x 768 dots/1280 x 1024 dots/
1600 x 1200 dots)*
4
80 GB*
5
88 keys
720 KB/1.44 MB (two-mode)
Two Type I or Type II, or one Type III
3.3 V: 400 mA
5 V: 400 mA
200 pin, 1.8 V, SO-DIMM, DDR2 SDRAM, PC2-3200 Compliant
SD Memory Card
Dsub 25-pin female
Mini Dsub 15-pin female
Dsub 9-pin male
Miniature jack, 3.5 DIA
Miniature jack, 3.5 DIA, Impedance 32 Ω, Output Power 4 mW x 2
Dedicated 80-pin female
4-pin x 2, USB 2.0
RJ-11 jack, Data: 56 kbps (V.92 & K56flex*
9
) FAX: 14.4 kbps
RJ-45 jack, IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab
1000Base-T
Built-in Intel
®
PRO/Wireless 2915 ABG ( page 44)
Dedicated 50 Ω coaxial connector
Touch Pad Touch Pad
Touchscreen (Anti-Reflection, Stylus (in-
cluded) touch capable)
WAVE and MIDI playback, Monaural Speaker (built in)
This page provides the specifications for the basic model CF-29LTQGZBE/CF-29LTQGZL2/CF-29L3QGZBE/CF-29L3QGZL2.
The model number will change depending on the configuration of the unit, such as, CPU speed, memory size, HDD size, Operating
System, LCD type, and whether a wireless LAN is built in or not.
To check the model number:
Check the bottom of the computer or the box the computer came in at the time of purchase.
To check CPU speed, memory size and the hard disk drive (HDD) size:
Run the Setup Utility (
“Setup Utility”).
Confirm the required information by checking the following items.
• [Information] menu
CPU speed: [CPU Speed] Memory size: [System Memory] Hard disk drive size: [Primary Master]
• [Advanced] menu
Wireless LAN: [Wireless LAN] is displayed only if a wireless LAN is built in.

Panasonic CF-29 Series Specifications

General

Display	13.3-inch LCD
Resolution	1024x768 pixels
Weight	7.8 lbs
Operating System	Windows XP
Rugged Features	MIL-STD-810F certified
Ports	USB, VGA, serial, parallel, Ethernet, modem, audio in/out
Wireless	Wi-Fi 802.11b/g
Dimensions	11.9" x 9.4" x 2.5"
Battery Life	Up to 4 hours (depending on configuration and usage)
