10 REPLACEMENT PARTS
LIST
Notes :
1. Be sure to make your orders of replacement parts
according to this list.
2. Important safety notice: Components, identified by
mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3. Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4. The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
5. "MCC" marks in remarks column are indicated supply parts
of Matsushita Communication Industrial Corp. of America
(MCC).
6. "A" or "B" marks in remarks column are indicated as
follows :
·
A : CQ-JT1010X
·
B : CQ-JS6910X
Ref.
No.
Part No. Part Name & Description Remarks
[E6741B] Main Block
IC´s and TRANSISTORs
IC201 C1BB00000284 IC
IC202 YEAMPC4570E1 IC
IC231 AN7550NZ IC
IC601 C2BBGF000090 IC
IC701 C0DBZHZ00005 IC
IC702 AN7805 IC
IC791 C1BB00000034 IC
IC801 C0GBG0000004 IC
IC851 C1BB00000100 IC
PA101 YMP0PTA514B0 Electronic Tuner MCC
Q271 B1GDCFNN0003 Transistor
Q451 B1CBGF000001 Transistor
Q651 2SB14460HA Transistor
Q731 B1BCDG000005 Transistor
Q761 B1GDCFNN0003 Transistor
Q762 B1GBCFNN0005 Transistor
Q764 B1BBCF000009 Transistor
Q767 B1BBCF000009 Transistor
Q771 2SD10300HL Transistor
Q772 2SB14400HL Transistor
Q773 2SD10300HL Transistor
Q774 2SB14400HL Transistor
Q851 B1GBCFJN0005 Transistor
DIODEs
D201 B0BC3R900008 Diode
D271 B0ACCE000001 Diode
D272 MA151WKTX Diode
D273 B0ACCE000001 Diode
D686 MA151WATX Diode
D700 B0JCPE000004 Diode
D701 B0EANM000003 Diode
D751 B0BC4R600003 Diode
D752 B0BC4R600003 Diode
Ref.
No.
Part No. Part Name & Description Remarks
D753 B0BC4R600003 Diode
D754 B0ECKL000001 Diode
D755 B0ECKL000001 Diode
D761 B0BC5R000004 Diode
D771 B0BC8R100002 Diode
D772 B0BC8R100002 Diode
D791 B0BC5R600004 Diode
D792 B0BC5R600004 Diode
D821 B0ACCE000001 Diode
D831 B0ACCE000001 Diode
D871 MA151WATX Diode
R235 B0BC01000003 Diode
CAPACITORs
C50 F1J1H120A025 Ceramic, 12PF 50WV
C51 F1J1H102A509 Ceramic, 1000PF 50WV
C56 F1J1H102A509 Ceramic, 1000PF 50WV
C57 F1J1H102A509 Ceramic, 1000PF 50WV
C100 ECA1CM100I Electrolytic, 10µF 16WV
C101 F1J1H103A509 Ceramic, 0.01µF 50WV
C105 YECUS1C224KX Ceramic, 0.22µF 16WV
C106 F1J1H103A509 Ceramic, 0.01µF 50WV
C107 F1J1E223A002 Ceramic, 0.022µF 25WV
C108 EEUFC1A221B Electrolytic, 220µF 10WV
C109 F1J1E223A002 Ceramic, 0.022µF 25WV
C121 F1J1E223A002 Ceramic, 0.022µF 25WV
C122 F1J1H103A509 Ceramic, 0.01µF 50WV
C123 ECA1HM2R2I Electrolytic, 2.2µF 50WV
C131 F1J1E223A002 Ceramic, 0.022µF 25WV
C132 F1J1H103A509 Ceramic, 0.01µF 50WV
C133 ECA1HM2R2I Electrolytic, 2.2µF 50WV
C151 F1J1H151A034 Ceramic, 150PF 50WV
C152 F1J1H471A025 Ceramic, 470PF 50WV
C153 ECA1CM100B Electrolytic, 10µF 16WV
C155 F1J1H103A509 Ceramic, 0.01µF 50WV
C156 F1J1E223A002 Ceramic, 0.022µF 25WV
C157 EEUFC1A221B Electrolytic, 220µF 10WV
C201 F1J1H103A509 Ceramic, 0.01µF 50WV
C202 ECA0JM331B Electrolytic, 330µF 6.3WV
C203 ECA1HM010B Electrolytic, 1µF 50WV
C204 ECA1HM010B Electrolytic, 1µF 50WV
C205 YECUS1A105KX Ceramic, 1µF 10WV
C206 F1J1H102A509 Ceramic, 1000PF 50WV
C208 F1J1C6830001 Ceramic, 0.068µF 16WV
C209 F1J1C6830001 Ceramic, 0.068µF 16WV
C210 F1J1H103A509 Ceramic, 0.01µF 50WV
C211 YECUS1A105KX Ceramic, 1µF 10WV
C214 F1J1E4730003 Ceramic, 0.047µF 25WV
C216 F1J1E333A002 Ceramic, 0.033µF 25WV
C217 ECA1HMR33B Electrolytic, 0.33µF 50WV
C218 F1J1E4730003 Ceramic, 0.047µF 25WV
C231 YECUV1C224KX Ceramic, 0.22µF 16WV
C232 YECUV1C224KX Ceramic, 0.22µF 16WV
C233 YECUV1C224KX Ceramic, 0.22µF 16WV
C234 YECUV1C224KX Ceramic, 0.22µF 16WV
C235 ECA1CM330B Electrolytic, 33µF 16WV
C271 ECA1HM010B Electrolytic, 1µF 50WV
C281 F1J1H221A025 Ceramic, 220PF 50WV
C282 F1J1H221A025 Ceramic, 220PF 50WV
C301 F1J1H103A509 Ceramic, 0.01µF 50WV
C302 ECA1CM470B Electrolytic, 47µF 16WV
C303 ECA1HM010B Electrolytic, 1µF 50WV
C304 ECA1HM010B Electrolytic, 1µF 50WV
C305 YECUS1A105KX Ceramic, 1µF 10WV
C306 F1J1H102A509 Ceramic, 1000PF 50WV
C308 F1J1C6830001 Ceramic, 0.068µF 16WV
C309 F1J1C6830001 Ceramic, 0.068µF 16WV
C310 F1J1H103A509 Ceramic, 0.01µF 50WV
C311 YECUS1A105KX Ceramic, 1µF 10WV
C314 F1J1H103A509 Ceramic, 0.01µF 50WV
C315 ECA1CM470B Electrolytic, 47µF 16WV
C316 F1J1E333A002 Ceramic, 0.033µF 25WV
13
CQ-JT1010X / CQ-JS6910X
