CS-A28BKP5/CU-A28BKP5
(Note)
NO DESCRIPTION & NAME QTY CS-A28BKP5 REMARKS
1 CHASSIS COMPLETE 1 CWC5239-970
●
2 FAN MOTOR 1 CWC4301-370
■ ●
3 CROSS FLOW FAN COMPLETE 1 CWC5707-260
●
4 BEARING ASS’Y 1 CWC4059-190
●
5 SCREW (CROSS FLOW FAN) 1 CWC4582-660
●
6 EVAPORATOR COMPLETE ASS'Y 1 CWC6325-300
●
7 TUBE ASS’Y COMPLETE 1 CWC5811-260
●
8 INSTALLATION PLATE 1 CWC8010-540
●
9 SENSOR HOLDER 1 CWC5040-130
●
10 PARTICULAR PLATE 1 CWC4945-610
●
11 DISCHARGE GRILLE COMPLETE 1 CWC5011-920
●
12 FULCRUM 3 CWC4525-110
●
13 MOTOR - AIR SWING 1 CWC4107-010
■●
14 VANE AIR DEFLECTOR ASS’Y 1 CWC5050-870
●
15 DRAIN HOSE 1 CWC5881-720
●
16 TRANSFORMER 1 CWC4017-690
●
17 CONTROL BOARD ASS’Y 1 CWC4719-220
●
18 PARTICULAR PLATE 1 CWC4945-600
■●
19 1
■ ●
20 CIRCUIT ASS’Y (OPERATION BUTTON COMPLETE) 1 CWC3919-720
■●
21 CIRCUIT ASS’Y (RECEIVER COMPLETE) 1 CWC3919-640
■●
22 CIRCUIT ASS’Y (DISPLAY COMPLETE) 1 CWC3919-710
■ ●
23 CIRCUIT ASS’Y (ELECTRONIC CONTROLLER) 1 CWC3919-420A
■ ●
24 TERMINAL BOARD ASS’Y 1 CWC4706-600
■●
25 1
●
27 TERMINAL BOARD COMPLETE 1 CWC4706-620
●
28 SENSOR COMPLETE 1 CWC3900-230
■●
29 CONTROL BOARD TOP COVER 1 CWC4945-590
●
30 HOLDER - P.S. CORD 1 CWC4627-040
●
31 CAP (BUTTON) 1 CWC5060-120
■ ●
32 REMOTE CONTROL COMPLETE ASS’Y 1 CWA75C556
33 FRONT GRILLE COMPLETE 1 CWC5053-360
34 DECORATING PLATE COMPLETE 1 CWC5027-410
●
35 DOOR 1 CWC5002-270
36 INTAKE GRILLE COMPLETE 1 CWC5010-960
●
37 AIR FILTER (LEFT) 1 CWD4209550
■ ●
38 AIR FILTER (RIGHT) 1 CWD4209540
■ ●
39 SCREW - FRONT GRILLE 4 XTT4+16C
●
40 CAP (FRONT GRILLE COMPLETE) 4 CWC5060-060
●
41 BAG COMPLETE (AIR PURIFYING FILTER) 1 CWC4649-920
●
42 SOLAR REFESHING DEODORIZING FILTER 1 CZ-SFD71P
●
43 CATECHIN AIR PURIFYING FILTER 1 CZ-SF71P
●
44
45 1
●
OPERATING INSTRUCTIONS
1
CWC8037-130
INSTALLATION INSTRUCTIONS CWC8039-270
BAG COMPLETE - INSTALLATION SCREW
CWC4649-210
•
“
■
” marked parts are recommended to be kept in stock.
•
“
●
” marked parts are supplied from TAMACO, Taiwan.
•
“
▲
” marked parts are supplied from MACC, Malaysia.
68
16 Replacement Parts List
<Model: CS-A28BKP5>
26 FUSE COMPLETE
1
CWC4023-070
■●
■ ●
●
●
POWER SUPPLY COMPLETE CWC4102-760
■▲
