8
2.3. CS-A12GKD CU-A12GKD
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
Item Unit Indoor unit Outdoor unit
Performance Test Condition JIS
C Capacity kW 3.52 - 3.54
O BTU/h 12000 - 12100
O kcal/h 3030 - 3040
L EER W/W 3.26 - 3.16
I BTU/hW 11.1 - 10.8
N Noise Level dB (A) High: 39 Low: 29 High: 48 - 49
G Power level dB High: 52 High: 63 - 64
H Capacity kW 4.00 - 4.05
E BTU/h 13640 - 13810
A kcal/h 3440 - 3480
T Cop W/W 3.67 - 3.62
I BTU/hW 12.5 - 12.3
N Noise Level dB (A) High: 40 Low: 29 High: 48 - 49
G Power level dB High: 53 High: 64 - 65
Moisture Removal l/h 2.0
(pt/h) 4.2
Air Volume Lo
m
3
/m (ft
3
/m)
Cooling; 6.1 (220)
Heating; 6.5 (230)
—
Me
m
3
/m (ft
3
/m)
Cooling; 8.5 (300)
Heating; 8.5 (300)
—
Hi
m
3
/m (ft
3
/m)
Cooling; 9.9 (350)
Heating; 10.0 (350)
Cooling;
32.5 (1150) - 33.0 (1160)
SHi
m
3
/m (ft
3
/m)
Cooling; 10.1 (360) —
Refrigerant Control Device — Capillary Tube
Refrigerant Oil (Charged)
cm
3
— ATMOS M60 or
SUNISO 4GDID (410cm
3
)
Refrigerant (Charged) R22 kg (oz) — 1.05 (37.1)
Dimension Height mm (inch) 280 (11 - 1/32) 540 (21 - 1/4)
Width mm (inch) 799 (31 - 15/32) 780 (30 - 23/32)
Depth mm (inch) 183 (7 - 7/32) 289 (11 - 3/8)
Net Weight kg (lbs) 9 (20) 37 (82)
Pipe Diameter Gas mm (inch) 12.70 (1/2”)
Liquid mm (inch) 6.35 (1/4”)
Height Difference m (ft) 5 (16.4)
Pipe Length Range m (ft) 3 (9.8) ~ 15 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose Inner diameter mm 16 —
Length mm 650 —
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 950
Fan Type Cross-flow Fan Propeller Fan
Material ASG20K1 PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input power W 42 - 47 72 - 80
Output power W 15 31
Fan Speed Lo (Cool / Heat) rpm 800 / 860 —
Me (Cool / Heat) rpm 1120 / 1120 —
Hi (Cool / Heat) rpm 1300 / 1320 845 - 860 / —
SHi (Cool / Heat) rpm 1320 / — —
Heat Exchanger Fin material Aluminium (Pre Coat) Aluminium
Fin Type Slit Fin Louver Fin
Row × Stage × FPI 2 × 15 × 21 2 × 24 × 16
Size (W × H × L) mm (inch) 610 × 315 × 25.4 36.38 × 504 × 713:684
Air Filter Type Material Polypropelene —
Style One-touch —
To Next Page
