13.2. Heating Capacity Performance Data
HC: Heating Capacity
IPT: Heating Power Consumption
Ambient Temperature Air Entering Condenser (°C D.B.)
Model Power Return -6°C0°C6°C12°C
(CS-) Source Air HC IPT HC IPT HC IPT HC IPT
D.B. kW kW kW kW kW kW kW kW
230V, 15 5.18 1.65 6.21 1.89 7.46 2.24 8.66 2.64
F24DB4E5 50Hz, 20 4.90 1.75 5.86 2.01 7.10 2.36 8.52 2.74
1 phase 25 4.62 1.84 5.54 2.12 6.75 2.48 8.17 2.80
230V, 15 5.84 1.82 7.00 2.08 8.40 2.47 9.76 2.91
50Hz,
F28DB4E5 1 phase 20 5.52 1.92 6.60 2.21 8.00 2.60 9.60 3.02
400V,
50Hz, 25 5.20 2.03 6.24 2.34 7.60 2.73 9.20 3.05
3 phase
230V, 15 8.18 2.70 9.80 3.09 11.76 3.67 13.66 4.32
F34DB4E5 50Hz, 20 7.73 2.86 9.24 3.28 11.20 3.86 13.44 4.48
1 phase 25 7.28 3.01 8.74 3.47 10.64 4.05 12.88 4.57
400V, 15 8.18 2.65 9.80 3.02 11.76 3.59 13.66 4.23
F34DB4E5 50Hz, 20 7.73 2.80 9.24 3.21 11.20 3.78 13.44 4.38
3 phase 25 7.28 2.95 8.74 3.40 10.64 3.97 12.88 4.48
400V, 15 10.22 3.28 12.25 3.75 14.70 4.46 17.08 5.25
F43DB4E5 50Hz, 20 9.66 3.47 11.55 3.99 14.00 4.69 16.80 5.44
3 phase 25 9.10 3.66 10.92 4.22 13.30 4.92 16.10 5.56
400V, 15 10.95 3.52 13.13 4.02 15.75 4.78 18.30 5.63
F50DB4E5 50Hz, 20 10.35 3.72 12.38 4.28 15.00 5.03 18.00 5.83
3 phase 25 9.75 3.92 11.70 4.53 14.25 5.28 17.25 5.96
