12
3.4. CS-F34DB4E5 CU-B34DBE5
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F34DB4E5 CU-B34DBE5
Panel CZ-BT03P
Remote
Control
CZ-RD513C (Wired)
CZ-RL513B (Wireless)
Cooling Capacity kW 10
BTU/h 34,100
Heating Capacity kW 11.20
BTU/h 38,200
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
27 94
cfm 954 3316
Outside Dimension (H x W x D) mm 288 x 840 x 840 1170 x 900 x 320
inch 11-5/16 x 33-1/24 x 33-1/24 46-1/16 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 28.5 (63) 102 (225)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain O.D Ø 20 I.D Ø 20
Compressor Type, Number of Set - Hermetic, 1
Starting Method - Permanent Split Capacitor
Motor Type - 2-pole 1 phase brushless motor
Rated Output kW - 3.00
Fan Type, Number of Set Turbo fan-1 Mix flow fan,2
Motor Type 8-pole DC motor 6-pole single phase induction motor
Rated Output kW 0.06 0.07 x 2
Air-heat Exchanger (Row x Stage x FPI) Louver-fin type (2 x 12 x 21) Corrugate-fin type (2 x 44 x 20)
Refrigerant Control - Expansion Valve
Refrigerant Oil (Charged)
cm
3
- DAPHNE FV68D (1500)
Refrigerant (Charged) R410a kg (oz) - 2.70 (95)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat -
Noise Level dB (A) Cooling: 42/37 55/-
Heating: 42/37 56/-
Power Level
dB
Cooling: 57/52 69/-
Heating: 57/52 70/-
Moisture Removal L/h (Pt/h) 6.0 (12.6)
EER W/W 2.66/2.62/2.59
COP W/W 2.94/2.9/2.86
ITEM / MODEL Condition by ISO5151
Volts V 220 230 240
Phase Single Single Single
Power Consumption kW Cooling 3.76 3.81 3.86
Heating 3.81 3.86 3.91
Running Current A Cooling 17.8 18.1 18.4
Heating 17.5 17.7 17.9
Starting Current A 92 95 98
Power Factor % Cooling 96 92 87
Heating 99 95 91
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V,230V, 240V 50Hz
