Panasonic DMP-UB900 User Manual

40
TQBA2018
Specifications
≥ Specifications are subject to change without notice.
General
Signal system NTSC
Operating temperature
range
i5 oC to i35 oC
(i41 oF to i95 oF)
Operating humidity
range
10 % to 80 % RH
(no condensation)
AUDIO OUT (Pin jack) Analog Audio output (L/R,
7.1ch):
Standard : 0.5 Vrms,
Full scale : 2.0 Vrms at 1 kHz
(<500 ≠)
Audio performance Frequency response:
4 Hz to 88 kHz
S/N ratio:
115 dB (2ch L/R, FL/FR)
Dynamic range:
110 dB (2ch L/R, FL/FR)
DIGITAL AUDIO OUT
(OPTICAL/COAXIAL)
1pc.
Output format : PCM, Dolby
Digital, DTS
®
HDMI OUT
(19 pin type A)
2 pcs.
Output Audio format : PCM,
Dolby Digital, Dolby Digital Plus,
Dolby TrueHD, DTS
®
, DTS-HD
High Resolution Audio
TM
,
DTS-HD Master Audio
TM
USB port (Type A) 1pc.
SD card slot 1pc.
LAN (Ethernet) Port 1pc.
10BASE-T/100BASE-TX/
1000BASE-T
Wireless LAN Standard Compliance:
IEEE802.11 a/b/g/n/ac
Frequency Range:
2.4 GHz/5 GHz band
Security:
WPA
TM
/WPA2
TM
(Encryption
type: TKIP/AES, Authentication
type: PSK), WEP (64 bit/128 bit)
LASER Specification
Class
I LASER Product
Wave length: 777-800 nm (CDs)/
650-665 nm (DVDs)/
400-410 nm (BDs)
Laser power: No hazardous radiation
is emitted with the safety protection
Power supply
AC
() 120 V, 60 Hz
Power consumption Approx. 25 W
Power consumption in
standby mode
Approx. 0.2 W
(Quick Start: Off)
Power consumption in
quick start standby mode
Approx. 8 W
(Quick Start: On)
Dimensions (WkHkD)
Including the projecting
parts
435 mmk68 mmk207 mm
(Approx.
17
3/16zk2 11/16zk8 3/16z)
Mass (Weight)
Approx. 2.4 kg
( 5.3 lbs)
File format
File format Extension Reference
MKV
“.MKV”, “.mkv” ≥ The video file and
subtitles text file are
inside the same folder,
and the file names are
the same except for the
file extensions.
≥ Some MKV files may
not be played back
correctly, depending on
the video resolution,
frame rate condition,
subtitle format and so
on.
≥ MOTION JPEG is not
supported.
Subtitles text file
“.SRT”, “.srt”,
“.SSA”, “.ssa”,
“.ASS”, “.ass”
mp4
( Compression
methods
Video: H.264
Audio: AAC
)
“.MP4”, “.mp4”,
“.MOV”, “.mov”
≥ Resolution up to
3840×2160 30p,
4096×2160 24p. (MP4
only)
≥ Some mp4/MPEG files
may not be played
back correctly,
depending on the video
resolution, frame rate
condition and so on.
≥ MOTION JPEG is not
supported.
≥ Depending on the
audio compression
method, only images
may be played back
and it may not be
possible to output
audio.
MPEG
(TS/PS)
“.MPG”, “.mpg”,
“.MPEG”, “.mpeg”,
“.M2TS”, “.m2ts”,
“.MTS”, “.mts”,
“.TS”, “.ts”
JPEG “.JPG”, “.jpg”
≥ MOTION JPEG and
Progressive JPEG are
not supported.
≥ You may not be able to
play back the file if you
have edited the folder
structure or the file
name on a PC or other
device.
MPO “.MPO”, “.mpo” 3D still picture
MP3 “.MP3”, “.mp3”
This unit supports ID3
tags, but only titles, artist
names and album names
can be displayed.
FLAC “.FLAC”, “.flac”
This unit supports tags,
but only titles, artist
names and album names
can be displayed.
Maximum sampling rate:
192 kHz/24 bit
WAV “.WAV”, “.wav”
Maximum sampling rate:
192 kHz/32 bit
AAC “.M4A”, “.m4a”
Maximum sampling rate:
48 kHz/320 kbps
DMP-UB900_P-TQBA2018.book 40 ページ ２０１６年６月８日 水曜日 午後４時４９分

Panasonic DMP-UB900 Specifications

General

3D	Yes
Depth	199 mm
Width	435 mm
Height	68 mm
Weight	2400 g
Video apps	Netflix, YouTube
Device type	Blu-Ray player
Product color	Black
Audio decoders	DSD, DTS-HD HR, DTS-HD Master Audio, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, THX Surround EX
AC input voltage	120 V
AC input frequency	60 Hz
Disc types supported	BD-R, BD-R DL, BD-RE, BD-RE DL, BD-ROM, CD, CD-R, CD-RW, DVD, DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-R DL, DVD-RW
Recording disc types	DVD-R, DVD-R DL, DVD-RW
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Compatible memory cards	SD, SDHC, SDXC
Image formats supported	JPEG XR, MPO
Video formats supported	AVCHD, MKV, MPO
Digital audio optical out	-
Analog signal format system	NTSC
Power consumption (standby)	0.2 W
Power consumption (typical)	25 W
Consumer Electronics Control (CEC)	VIERA Link
Audio output channels	7.1 channels
TV tuner type	Analog
