Panasonic Lumix DC-GH5SP User Manual

25
7 Troubleshooting Guide
7.1. Checking Method of Body
1. Initial Inspection Tips (Before Determine The Unit Being Faulty/Defective):
Since this unit is equipped with various functions/settings, some phenomenon/effect might be caused by miss usage of func-
tion and/or settings.
It might be made a miss-judgement caused by miss usage of function & settings although the unit is working properly without
fault.
Therefore, check/confirm the followings before concluding/determine the unit being faulty/defective.
NOTE: Refer to the Operating Instructions about content of various settings.
If it is hard to determine whether the resolution is out of specification or not, proceed the “RESOLUTION INSPECTION”,
before replacing the Lens Main Unit. (The unit might be mishandling, dropping or others.)
2. Reference information

Panasonic Lumix DC-GH5SP Specifications

General

Type	mirrorless camera body only
Color	black
Image Sensor	nmos
Image Sensor Size	four thirds (17.3 x 13 mm)
Effective Pixels	10.28 megapixels
Digital Zoom	4x
File Format	avchd, exif, jpeg, mov, mp4, raw
Viewfinder Type	electronic
Brightness Control	yes
Built In Flash	no
Flash Mount	hot shoe
Lens Mount	micro four thirds
Shutter Speed	electronic and mechanical: 60-1/8000 second; 30- 1 minute in bulb mode; 1/24-1/16000 second in movie mode; electronic: 1-16000 second
White Balance	awb; awbc; daylight; cloudy; shade; incandescent; flash; white; set 1, 2, 3, 4; color temperature setting 1, 2, 3, 4
Autofocus	yes
Eye AF	yes
Display Type	lcd
Display Size	3.2 inches
Display Resolution	1, 620, 000 dots
Video Resolution	4k (2160p)
Video Frame Rate	up to 60 fps
Wireless Connectivity	bluetooth, wifi, nfc
Interface Connectors	hdmi, usb
Memory Card Slots	2
Memory Card Type	secure digital, secure digital high capacity (sdhc)
Battery	dmw-blf19
Waterproof	yes

Weight and Dimensions

Depth	3.4 inches
Height	3.9 inches
Width	5.5 inches
Net Weight	1.46 pounds
