Panasonic LUMIX DMC-GX8 Basic Operating Instructions

Others
56
SQT0790 (ENG)
Troubleshooting
First, try out the following procedures.
•
Please also refer to the “Operating Instructions for advanced features (PDF format)”, which
describes more detailed information.
• The battery is exhausted.
> Charge the battery.
• If you leave the camera on, the battery will be exhausted.
> Turn the camera off frequently by using the [Economy] etc.
• Is the drive mode set to [ ] ([4K Pre-Burst])? When [ ] ([4K Pre-Burst]) is selected, the
battery drains faster.
> Select [ ] ([4K Pre-Burst]) only when recording.
• When the drive mode is set to [ ] ([4K Pre-Burst]), the camera temperature rises. In some
cases, the camera may display [ ], switch to [ ] ([4K Burst]) and stop the recording to
protect itself. Wait until the camera cools down.
• The subject is beyond the focus range of the camera. (P19)
• There is camera shake (jitter) or the subject is moving slightly.
• Is [Focus/Release Priority] in the [Custom] menu set to [RELEASE]?
• Is [Shutter AF] in the [Custom] menu set to [OFF]?
• Is the AF Lock applied incorrectly?
• The shutter speed will become slower and the Image Stabiliser function may not work properly
when taking pictures especially in dark places.
> We recommend holding the camera firmly with both hands when taking pictures.
> We recommend using a tripod and the self-timer when taking pictures with a slow shutter
speed.
• When a moving subject is recorded with the electronic shutter, the subject may appear
distorted on the picture.
If the problem is not resolved, it may be improved by selecting [Reset] on the
[Setup] menu.
The camera cannot be operated even when it is turned on.
The camera turns off immediately after it is turned on.
The battery becomes flat too quickly.
Taking pictures is not possible.
The shutter will not operate immediately when the shutter button is pressed.
The subject is not focused properly.
The recorded picture is blurred.
The Image Stabiliser is not effective.
DMC-GX8A&GX8H&GX8K_GCGH-SQT0790_eng.book 56 ページ ２０１５年７月８日 水曜日 午前９時１１分

Panasonic LUMIX DMC-GX8 Specifications

General

Camera type	MILC Body
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.77 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5184 x 3888, 3712 x 2784, 2624 x 1968, 1824 x 1368, 5184 x 3456, 3712 x 2480, 2624 x 1752, 1824 x 1216, 5184 x 2920, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3888 x 3888, 2784 x 2784, 1968 x 1968, 1712 x 1712
Digital zoom	- x
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Forced on, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed	1/250 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@30fps
Audio system	Mono
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
Magnification	0.77 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Eye relief	21 mm
Scene modes	Panorama, Portrait, Landscape (scenery)
Image editing	Crop, Rotating
Photo effects	Black&White, Sepia, Vivid
White balance	ATW, Auto, Cloudy, Daylight, Flash, Halogen, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
GPS (satellite)	No
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	330 shots
Product color	Black
Cables included	USB

Weight and Dimensions

Depth	61.3 mm
Width	133.2 mm
Height	77.9 mm
Weight	435 g
Lens length	63.6 mm
Lens weight	165 g
Lens diameter	60.6 mm
Weight (including battery)	487 g
