326
SQW0021
Others
Usage cautions and notes
When in use
Camera may become warm if used for long periods of time, but this is not a fault.
Keep this unit as far away as possible from electromagnetic equipment (such as
microwave ovens, TVs, video games etc.).
If you use this unit on top of or near a TV, the pictures and/or sound on this unit may
be disrupted by electromagnetic wave radiation.
Do not use this unit near cell phones because doing so may result in noise adversely
affecting the pictures and/or sound.
Recorded data may be damaged, or pictures may be distorted, by strong magnetic
fields created by speakers or large motors.
Electromagnetic wave radiation may adversely affect this unit, disturbing the pictures
and/or sound.
If this unit is adversely affected by electromagnetic equipment and stops functioning
properly, turn this unit off and remove the battery or disconnect AC adaptor (optional).
Then reinsert the battery or reconnect AC adaptor and turn this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
If you record near radio transmitters or high-voltage lines, the recorded pictures and/
or sound may be adversely affected.
Do not extend the supplied cord or cable.
Do not allow camera to come into contact with pesticides or volatile substances (can
cause surface damage or coating to peel).
Do not keep objects that may be influenced magnetically close to the speaker.
Magnetized objects such as bank cards, commuter passes, watches, may be
adversely affected by the magnetic influence of the speaker.
Never leave the camera and the battery in a car or on a car hood in the summer.
Doing so may cause leakage of the battery electrolyte, overheating, fire or a battery
explosion due to the high temperature.
Caring for your camera
To clean your camera, remove the battery or the DC coupler (optional), or disconnect the
power plug from the outlet, and wipe with a soft, dry cloth.
Use a damp cloth to remove stubborn stains, before wiping with a dry cloth.
Do not use benzine, thinners, alcohol, or kitchen detergent, as these may damage the
outer casing and finish of the camera.
If using a chemically-treated cloth, read the supplied instructions carefully.

Table of Contents

Other manuals for Panasonic Lumix DMC-LX100

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-LX100 and is the answer not in the manual?

Panasonic Lumix DMC-LX100 Specifications

General IconGeneral
Megapixel12.8 MP
Camera typeCompact camera
Sensor typeMOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size4/3 \
Image formats supportedJPG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4112 x 3088 pixels
Still image resolution(s)[4:3] 4112x3088 (12.5M) (L) / 2976x2232 (6.5M) (M) / 2048x1536 (3M) (S)/[3:2] 4272x2856 (12M) (L) / 3120x2086 (6.5M) (M) / 2112x1408 (3M) (S)/[16:9] 4480x2520 (11M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)/[1:1] 3088x3088 (10M) (L) / 2240x2240 (5M) (M) / 1536x1536 (2.5M) (S)
Digital zoom4 x
Optical zoom3.1 x
Focal length range10.9 - 34 mm
Maximum aperture number16
Minimum aperture number1.7
Lens structure (elements/groups)11/8
Maximum focal length (35mm film equiv)75 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto/Manual
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)51200
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)0.3 - 8.5 m
Flash range (wide)0.6 - 14.1 m
Shoe mounting point typeHot shoe
Video resolutions1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution3840 x 2160 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x960@25fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@50fps
Audio formats supportedAAC
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Vari-angle LCD displayNo
Display resolution (numeric)921000 pixels
Magnification1.39 x
Viewfinder screen size0.38 \
USB version-
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Image editingCrop, Resizing, Rotating
Photo effectsArt, Black&White, Neutral, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playbackSlide show, Thumbnails
Image processorVenus
Self-timer delay2, 10 s
Camera file systemDCF, DPOF, Exif 2.3, RAW
Image quality adjustmentColour depth, Contrast, Saturation, Sharpness
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Power source typeBattery
Battery voltage7.2 V
Battery capacity1025 mAh
Battery life (CIPA standard)350 shots
Product colorSilver
Cables includedAC, USB
Bundled softwarePHOTOfunSTUDIO 9.6PE/SILKYPIX Developer Studio\\r LoiLoScope (trial)\\r Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth55 mm
Width114.8 mm
Height66.2 mm
Weight351 g
Weight (including battery)393 g
