3WAY SYSTEM
Control Functions
1 - 2
1
1. Introduction
The 3WAY System is a system that allows multiple outdoor units to be connected. The outdoor units all contain
inverter compressors, and the system does not utilize the sub units that were used in earlier systems.
The outdoor unit where the unit No. is set to “1” includes the CCU (command controller unit) functions that are
used to control the entire system. As a result, the system will not operate if no outdoor unit has been set as unit
No. “1.”
Required settings for Test Run
Outdoor unit No. 1 Outdoor unit Nos. 2 ~ 3
At time of shipment On-site setting At time of shipment On-site setting
System address 1 System 1 ~ 30 1 Not necessary
No. of indoor units 1 1 ~ 52 units 1 Not necessary
No. of outdoor units 1 1 ~ 3 units 1 Not necessary
3 ~ 2 .soN tinU11 .oN tinU1.oN tinU
This system can be expanded to connect a maximum of 3 outdoor units. (The system maximum capacity is 48 HP.)
The CCU functions are disabled at all units except the unit that is set as unit No. 1. Therefore no problems will
result even if the system address, No. of indoor units, and No. of outdoor units settings are made at the other units.
However, making these settings may be convenient for manual backup operation, as it eliminates the necessity
of making the settings again if unit No. 1 fails. (If unit No. 1 fails, and the power supply to it is interrupted, it will be
necessary to set a different unit as unit No. 1 in order to use manual backup operation.)
