24
Specifications
● Basic
Power source: Rechargeable lithium ion battery: 2670 mAh or more
* Battery can be charged using Multi-Dock Charger (WV-BWC40D8),
or Single Dock Charger (WV-BWC40D1)
Power consumption: DC 3.6 V
Continuous operating time*
1
: About 12 hours
Full-charging term*
2
: About 4 hours (100 %)
Operating environment:
Ambient operating
temperature:
Ambient operating humidity:
−20 °C to +50 °C {−4 °F to +122 °F}
10 % to 100 %
Storage environment: Storage temperature: –20 °C to +60 °C {–4 °F to +140 °F}
Storage humidity: 10 % to 95 % (no condensation)
Built-in microphone: Nondirectional electret condenser microphone x4
Internal memory: 128 GB
Terminals: Bottom terminal for Multi-Dock Charger or Single Dock Charger
Waterproof*
3
: IP67/IP66 (IEC 60529), Type 4X (UL50E), NEMA 4X compliant
On-vehicle support: Compliant with MIL-STS-810G
Dimensions: 70 mm (W) x 86 mm (H) x 24 mm (D)
{2-3/4 inches (W) x 3-3/8 inches (H) x 15/16 inches (D)}
(Excluding projections)
Mass:
Approx. 170 g {0.38 lbs}
Finish: Main body: Polycarbonate resin, Lusterless black
*1 The measurement result is based on our original standard. It varies depending on BLE / Wire-
less LAN / GPS wave condition, Recording time, LCD brightness and the operating environ-
ment.
*2 When left charging at room temperature (25°C) using Multi-Dock Charger. The battery charg-
ing time varies depending on the operating environment and the operating condition of BWC.
*3 In a state that the Battery Pack is correctly installed.
