13 GB/IE
Garden pressure sprayer
Introduction
We congratulate you on the purchase of your
new product. You have chosen a high quality
product. Familiarise yourself with the product
before using it for the first time. In addition,
please carefully refer to the operating instruc-
tions and the safety advice below. Only use
the product as instructed and only for the in-
dicated field of application. Keep these instr
uc-
tions in a safe place. If you pass the product
on to anyone else, please ensure that you
also pass on all the documentation with it.
Proper use
The product is used for spraying liquids in the
home, garden and greenhouses. The spray-
ing of solvents or solvent-containing liquids
or oil is a particular example of improper use
of the product. This product is intended for
private use only.
The pressure spraying device is used only
for spraying the following fluids in the
house, garden or in greenhouses.
- Water,
- Mild, PH-neutral cleaning agents
The sprayed agent may only be sprayed in
the concentration specified by the manufac-
turer of the agent. If in doubt, consult the man
u-
facturer of the agent. The pressure spraying
device is designed for private use only.
Incorrect use includes, in particular, the
spraying of the following:
- Pesticides
- Weed sprays
- Disinfectants
- Fertilisers
- Solvents or liquids containing solvents
- Oil
- Easily flammable fluids
- Corrosive fluids such as acids or lye.
Description of parts
and features
1
Pump handle
2
Pump
3
Safety valve
4
Pressure gauge
5
Container
6
Carrying strap
7
Spray nozzle
8
Spray tube
9
Union nut (Suction hose)
10
Union nut (sprayer handle)
11
Spray tube handle
12
Suction hose
13
Trigger
Technical data
Container
dimensions (ø x H): approx. 170 x 389 mm
Overall weight,
empty: approx. 1.14 kg
Length of spray
tube: approx. 500 mm
Capacity: approx. 5 l
Permissible
operating pressure: approx. 2.5 bar
Operating
temperature: 0–40 °C
Carrying method: At the operator‘s side,
using the carrying strap
