5
GB CY
device is only approved for private use in
dry spaces.
Please note the information on saw blade
types.
Any other use that is not explicitly ap-
proved in these instructions may result in
damage to the equipment and represent a
serious danger to the user.
The user or operator is responsible for ac-
cidents causing injury to other people or
damage to property.
This equipment is not suitable for commer-
cial use. Commercial use will invalidate the
guarantee.
The device is part of the Parkside
X20VTEAM series and can be oper-
ated using Parkside X20VTEAM series
batteries. The batteries may only be
charged using chargers from the Parkside
X20VTEAM series.
General description
The illustration of the most im-
portant functional components
can be found on the front and
the back fold-out pages.
Extent of the delivery
Carefully unpack the trimmer and check
that it is complete:
• Cordless sabre saw
• Accessories:
- 2 saw blades for wood (HCS) –
“Swiss Made”
- 1 saw blade for metal (HSS) – “Swiss
Made”
- 1 Allen key
- Tension tear protection (already t-
ted)
- Slide shoe (already tted)
- Protective cover (already tted)
- Adapter for external dust extraction
(already tted)
- Parallel guide
• Storage case
• Instruction manual
Battery and charger are not
included.
Dispose of the packaging material cor-
rectly.
Description of functions
The cordless sabre saw has a pendulum
stroke device, a work light and a parallel
guide.
The notches for mitre angles allow you to
work precisely.
Please refer to the descriptions below for
information on how the operating elements
work.
Overview
1 Safety switch
2 On/Off switch
3 Handle
4 Connection for dust extraction
5 Baseplate
6 Switch for dust blower function
7 Hexagon socket screws (not vis-
ible)
8 Pendulum stroke switch
9 Guide roller
10 Chuck
11 Slide-in openings
12 Retaining screws
13 Guard
14 LED work light (not visible)
15 Protective cover
16 Saw blade for metal
