Generaldescription
The illustrations are on the
front and back fold-out page.
Extentofthedelivery
Carefully unpack the appliance and check
that it is complete:
- Cordless Drill
- Storage case
- Instruction Manual
The screwdriver bits and drill bits
shown in the diagram as well as
the rechargeable battery and char-
ger are not included in delivery.
Overview
1 Keyless drill chuck
2 Chuck ring
3 Torque adjustment ring
4 Battery Indicator
5 Speed selector
6 Direction of rotation switch
7 On/off switch
8 LED working light
9 Drill chuck aperture
10 Battery
11 Battery release button
12 Storage case
13 Charger
14 Bitholder
15 Magnetic bit holder
Functionaldescription
The cordless drill with two-speed gearing
has a 19+1 level torque adjustment, left/
right running, a removable keyless chuck,
a 6-point bitholder and an LED working
light.
Technical data
Cordless Drill ................PBSA 12 D4
Motor voltage U .......................... 12 V
Idling speed n
0
1st gear ............................. 0-350 min
-1
2nd gear .........................0-1300 min
-1
Maximum torque .......................... 28 Nm
Span-chuck ............................ 0.8-10 mm
Weight .................................. ca. 0.8 kg
Weight (accessories only) ............... 0.8 kg
Drilling capacity
for wood .......................... max. 25 mm
for steel ............................. max. 8 mm
Sound pressure level
(L
pA
) ................... 70.1 dB(A), K
pA
= 5 dB
Sound power level
(L
WA
) ................. 81.1 dB(A); K
WA
= 5 dB
Vibration (a
h
)
Drilling in metal .................. < 2.5 m/s
2
Screwdriving ...................... < 2.5 m/s
2
K= 1.5 m/s
2
Temperature.......................... max. 50°C
Charging process .................. 4 - 40°C
Operation ..........................-20 - 50°C
Storage ................................ 0 - 45°C
Attention! An up-to-date list
of battery compatibility can
be found at:
www.lidl.de/akku
This device can only be operated with
the following rechargeable batteries:
PAPK12A1, PAPK12A2, PAPK12B1,
PAPK12B2.
This type of battery may only be charged
with the following chargers: PLGK12A1,
PLGK12A2, PLGK12B2.
The stated vibration emission value was
measured in accordance with a standard
testing procedure and may be used to com-
pare one power tool to another.
