CORDLESS DRILL PABS 20-Li D4
Introduction
Congratulations on the purchase of your new ap-
pliance. You have selected a high-quality product.
The operating instructions are part of this product.
They contain important information about safety,
usage and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the range of applications specified. Please also
pass these operating instructions on to any future
owner.
Intended use
This appliance is designed for screwing and drill-
ing into wood, plastic and metal. Use this product
only as described and for the areas of applications
specified. Any other usage of or modification to the
appliance is deemed to be improper and carries a
significant risk of accidents. The manufacturer ac-
cepts no responsibility for damage(s) attributable
to misuse. This appliance is not intended for com-
mercial use.
Features
Gear selector
Bit holder (magnetic)
Rotational direction switch/lock
ON/OFF switch/speed control
Belt clip
Battery charge level button
Battery display LED
Battery pack
Release button for battery pack
LED work light
Chuck
Torque selection ring
High-speed charger
Red charge control LED
Green charge control LED
Package contents
1 cordless drill PABS 20-Li D4
1 high-speed battery charger PLG 20 A1
1 battery pack PAP 20 A1
1 bit PH2 50 mm
1 carrying case
1 set of operating instructions
Technical details
Cordless drill: PABS 20-Li D4
Rated voltage: 20 V (DC)
Rated idle speed: 1st gear: n
0
0–400 rpm
2nd gear: n
0
0–1400 rpm
Chuck clamping
range : max. Ø 13 mm
Max. drill diameter: Steel: 13 mm
Wood: 30 mm
Battery: PAP 20 A1
Type: LITHIUM ION
Rated voltage: 20 V
(DC)
Capacity: 2.0 Ah
Cells 5
High-speed battery charger: PLG 20 A1
INPUT:
Rated voltage: 230–240 V
~
, 50 Hz
(AC)
Rated power
consumption: 65 W
Fuse (internal): 3.15 A
T3.15A
OUTPUT:
Rated voltage: 21,5 V
(DC)
Rated current: 2.4 A
Charging time: approx. 60min.
Protection class: II /
(double insulation)

Parkside PABS 20-Li D4 Specifications

General

Battery Voltage	20 V
Battery Type	Lithium-Ion
No-load Speed	0-400 / 0-1400 rpm
Spindle Lock	Yes
Integrated LED Work Light	Yes
