General description
Extent of the delivery
Carefully unpack the appliance and check
that it is complete:
- Cordless Drill
- Battery-charger
- Battery
- Storage case
- Instruction Manual
Pictured bit and drill not included.
The illustrations are on the
front fold-out page.
Overview
1 Keyless drill chuck
2 Chuck ring
3 Torque adjustment ring
4 Speed selector
5 Direction of rotation switch
6 Battery
7 Battery release button
8 Battery Indicator
9 Activation button
Battery Indicator
10 Storage case
11 Green LED
12 Red LED
13 Charger
14 Charger power supply cord
15 On/off switch
16 LED working light
17 Bitholder
Functional description
The cordless drill with two-speed gearing
has a 17+1 level torque adjustment, left/
right running, a removable keyless chuck,
a 6-point bitholder and an LED working
light. Maximum torque of 20 Nm.
Technical data
Appliance
Motor voltage........................10,8 V
Idling speed ...........0-300/0-1050 min
-1
Span-chuck .........................0,8-10 mm
Weight (without battery charger) . 1.1 kg
Drilling capacity for wood . max. 25 mm
Drilling diameter for steel ..... max. 8 mm
Sound power level
(L
pA
) .............65.3 dB (A), K= 3 dB (A)
Sound power level (L
wA
)
Guaranteed .......................76 dB (A)
Measured ...... 73.3 dB (A); K= 3 dB (A)
Vibration (a
n
) ......................................
Drilling in metal ...............................
.................... < 2.5 m/s
2
, K= 1.5 m/s
2
Screwdriving without impact
.....................< 2.5 m/s
2
, K= 1.5 m/s
2
Battery (Li-Ion)
Nominal voltage ....................10,8 V
Capacity .................................. 1,3 Ah
Charging time .......................... ca. 1 h
Recharger ............. JLH201261500G
Nominal consumption ..................30 W
Uptake voltage/Input
....................... 100-240 V~, 50-60 Hz
Voltage output/Output
.............................12,6 V
1500 mA
Protection class .............................
II
Protection category ...................... IPX0
