Parkside PDSSAP 20-Li A1 User Manual

PDSSAP 20-Li A1
■ 44
│
GB
│
MT
CORDLESS IMPACT DRIVER
PDSSAP 20-LI A1
Introduction
Congratulations on the purchase of your new tool.
You have chosen a high-quality product. The oper-
ating instructions are part of this product. They
contain important information about safety, usage
and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the range of applications specified. Please also
pass all associated documents on to any future
owner(s).
Intended use
This appliance is intended for screwing in and
unscrewing screws as well as for tightening and
loosening nuts. The appliance has clockwise/anti-
clockwise rotation, a 1/4" hexagon socket bit
holder and an LED working light. The light on this
appliance is intended to illuminate the immediate
work area of the appliance. The rotary impact
function of the appliance enables the power of the
motor to be converted into uniform rotary impacts.
The impact mechanism comes into effect during
tightening and loosening.
The appliance is designed for use by adults. Young
people under 16 years of age may only use the
appliance under supervision. The manufacturer
accepts no liability for damages caused by
improper use or incorrect operation of the appli-
ance.
Use this appliance only as described and for the
application areas specified. The appliance is not
intended for commercial use. Any other usage or
modification of the appliance is deemed to be
improper and carries a significant risk of accidents.
The manufacturer accepts no responsibility for
damage attributable to misuse.
Features
 Tool holder
1a
Locking collar
 Rotation direction switch/lock
 Belt clip
 LED work light
 Torque display
 Torque preselection
 ON/OFF switch/speed control
 Battery pack*
 Release button for the battery pack
 High-speed charger*
- Battery display LED
3 Battery charge level button
! Red charge control LED
. Green charge control LED
Package contents
1 cordless impact driver
1 belt clip
1 carrying case
1 set of operating instructions
Technical specifications
Cordless Impact Driver PDSSAP 20-Li A1
Rated voltage 20 V (DC)
Gears 3-speed gearbox
Rated idle speed 1st gear n
0
0–1900 rpm
2nd gear n
0
0–2800 rpm
3rd gear n
0
0–3600 rpm
Impact frequency 1st gear 0–2200/min
2nd gear 0–3400/min
3rd gear 0–4300/min
Torque levels 1st level 120 Nm
2nd level 180 Nm
3rd level 226 Nm
Max. screw capacity M16
Tool holder 1/4" hexagon socket
IB_329780_PDSSAP20-LiA1_LB5.indb 44 07.08.20 13:57

Parkside PDSSAP 20-Li A1 Specifications

General

Battery Voltage	20 V
Torque	180 Nm
No-load Speed	0-2800 rpm
Chuck	1/4" Hex
Battery Type	Li-Ion
Chuck Type	Quick-release
Impact Rate	0-3200 bpm
Weight	1.1 kg (without battery)
