GB
9
Please note that our equipment has not been
designed for use in commercial, trade or
industrial applications. Our warranty will be
voided if the equipment is used in commercial,
trade or industrial businesses or for equivalent
purposes.
Only allow repairs and services to be carried out
by authorized professional repair shops.
Remember.
If the inner diameter of the hose is
insufficient and the length of the hose too
long, this will result in a loss of power on
the equipment.
6. Technical data
Max. permitted operating pressure 8 bar
Recommended pressure range 4 - 7.5 bar
Air consumption approx. 0.11 l/shot
Staple width 5.7 mm
Staple length 13 - 40 mm
Nail length 10 - 50 mm
Recommended hose diameter Diameter 9 mm
Weight approx. 1,3 kg
L
pA
sound pressure level 85.5 dB(A)
L
WA
sound power level 98.8 dB(A)
L
PC
sound pressure level 113.6 dB(A)
Vibration a
w
≤ 2.5 m/s
2
K uncertainty 27.93 %
These values for noise emissions are
equipment-based characteristic values and do
not reflect the noise generated at the place of
use. The noise generated at the place of use
will depend, for example, on the work area, the
workpiece, workpiece support and the number
of stapling/nailing operations.
The value given for vibration is an equipment-
based characteristic value and does not
represent the impact on the hand and arm
system when the equipment is used. The
impact on the hand and arm system when the
equipment is used will depend, for example, on
the force of the grip, the pressing force, the
direction in which you are working, the air
pressure setting, the workpiece and the
workpiece support.
Reduce noise generation and vibration to a
minimum!
■ Use only equipment that is in perfect
condition.
■ Maintain and clean the equipment regularly.
■ Adopt your way of working to the equipment.
■ Do not overload the equipment.
■ Have the equipment checked if necessary.
■ Switch off the equipment when not in use.
■ Wear gloves.
Compressed air quality:
Purified and with oil mist.
Air supply:
Via a conditioning unit with filter pressure
reducer and mist oiler connected to a
compressed air source.
Recommended capacity of the compressor:
Compressor with a capacity of approx. 250
l/min, which is the equivalent of engine power of
approx. 2.2 kW
Remember:
Wear the necessary protective clothing
when working with the stapler, in particular
safety goggles.
Pay attention to the safety regulations.
6.1 Safety goggles (SF026)
The safety goggles (Fig. 2/Item L) are intended
to provide protection for the eyes, against small
parts flying at high speed and are intended to
protect the user against injury.
For optimum protection the safety goggles
should be adjusted by lengthening or
shortening the strap to make them fit correctly.
Adjusting the goggles: Slide the strap along the
latch to adjust the length of the strap.
ID number, name and address of the test
