7GB
Introduction / Safety instructions
z Parts description for
“black” version
1
Viewing pane
2
Helmet casing
3
Solar cell
4
Rear lens
5
Headband
6
Rear control dial headband
7
Lateral control dial headband
8
UV filter
9
Darkening control
10
Test button
11
Delay setting
12
Sensitivity setting
13
Low battery display
14
LED light switch
15
Battery compartment
16
Bracket
17
Arc sensor
19
LED light
20
Darkening switch
z Parts description for
version “with flames”
1
Viewing pane
2
Helmet casing
3
Solar cell
4
Rear lens
5
Headband
6
Rear control dial headband
7
Lateral control dial headband
8
UV filter
9
Darkening control
10
Test button
11
Delay setting
12
Sensitivity setting
13
Low battery display
14
LED light switch
15
Battery compartment
17
Arc sensor
18
Slide
19
LED light
20
Darkening switch
z Technical specifications
Filter cassette size: 110x90x15 mm
Field of vision: 9.2x4.2 cm
Light condition: DIN 4
Dark condition: DIN 5 – DIN 9 /
DIN 9 – DIN 13
Cycle times
Light to dark: 0.23~0.72 ms
Dark to light: 0.1~2 s
Switching on/off
Filter: Fully automatic
Switching on/off
LED: manual
Energy supply: Solar cell
UV/IR protection: DIN 16
Operating temperature: -5 °C to +55 °C
Storage temperature: -20 °C to +70 °C
W
elding processes: MMA, MIG,
MAG, TIG,
plasma cutting and
plasma welding
Maximum service life:
approx. 5 years
Safety instructions
Please read the operating instruc-
tions with care and observe the
notes described. Familiarise
yourself with the device, its
proper use and the safety notes
based on these operating instruc-
tions. The rating plate contains
all technical data of this welding
helmet; please learn about the
technical features of this product.
