v1.0 | 52
13.3 L920 Part Number and Part Number Description
Optional Multi-Functional Base
The optional charging base is a countertop base that supports the A920 terminal. The base part number
is L920-BC-1E0. This base provides charging capabilities and is a simpler form of its multi-functional
counterpart.
The optional multi-function base is a countertop base that supports the A920 terminal. The base part
number is L920-BM-2E0. It charges the A920 as well as supports multiple communication and
peripheral ports.
The multifunctional base supports the following:
• Ports (2 x HOST USB 2.0)
• 1 x RS232 (Serial port)
• 1 x RJ45 (LAN)
• 1 x DC 5.5mm Power Port
13.4 L920-BC & L920-BM Serial Number Location and Format
The serial number is located both on the hardware box, as well as the base of the L920 itself. Please see
the image below for a reference to its location.
