OPERATING THE PUMP 18/20
THERMAL MODE
The sensor for Thermal Mode is in the drive, on top of the motor. This feature allows you to
set a speed (450-3450 RPM) that runs when the IntelliFlo® VSD2 Variable Speed Pump goes
into Thermal Mode. The temperature level that you wish Thermal Mode to start can also be
set.
IMPORTANT NOTE: This feature is for protection of the pump. Do not depend on the Thermal
Mode feature for freeze protection of the pool. Certain situations could cause the pump to
sense a different temperature than actual air temperature.
Your automation systems air temperature sensor should be used to sense actual temperature.
For example, if the pump is located indoors, the temperature of the room does not indicate
the outdoor temperature. The pump does not sense the water temperature.
To access the Thermal Mode menu:
1. Check that the green power LED is on.
2. Press Menu.
3. Use the Down arrow to scroll to “Thermal Mode” and press Select.
4. The factory default for Thermal Mode is “Enabled“. To disable Thermal Mode, press Select
to highlight “Enabled”.
5. Press the Up arrow - “Disabled” is displayed.
6. Press Save to save.
To Set Thermal Mode Speed and Pump Temperature:
Note: Thermal Mode features are only accessible if Thermal Mode is “Enabled”.
1. With “Thermal mode” displayed on the screen, press the down arrow - “Set speed” is
displayed. The factory default is 1000 RPM.
2. Press select to change the speed. The cursor will highlight the first column (ones).
3. Use the Up or Down arrows to set speed (450-3450 RPM). Press save.
4. Press the Down arrow. “Temperature” will display. (This value will determine at what
temperature the pump will activate Thermal Mode, default is 40° F/4.4° C).
5. Press Select to edit. Use the Up or Down arrow to adjust the settings.
6. Press Save to save the temperature setting.
Note: To cancel any changes, press Back to exit without saving.
7. Press Back to exit.
Thermal Mode Menu Options
THERMAL MODE
Disabled / Enabled - Default: Enabled
DISABLED/ENABLED
SET SPEED
40° F - 50° F (4.4° C - 10° C) Default: 40° F (4.4° C)
PUMP TEMPERATURE
To Next Page
