10
GB
Use the electropump for the applications listed on the nameplate.
Do not operate the pump dry, since lack of water could cause it to overheat. In this case, the water inside the system
gets very hot, so there is a risk of scalding. Take off the plug and let the system cool down.
Do not run the electropump with a completely closed delivery.
WARNING
WARNING
WARNING
STARTING THE UNIT (SEE FIG. 1)
CHAPTER 5
The single phase motors are protected from overloads by a thermal device installed in the winding.
The protection for the three phase motor must be installed by the user.
Supply cables and extensions should have a section below that of H07 RN-F.
The plug and connections should be protected by water splashes.
For connecting single phase motors see Fig. 2
For connecting three phase motors see Fig. 3
For connecting double voltage single phase motors see Fig. 4
OVERLOAD PROTECTION
INSTRUCTIONS FOR A SAFE PUMP START
• Avoid exposing the pump to humidity
• Protect the pump from rain, making
sure that there are no leaking fittings
over the pump
• Avoid using the pump in wet or damp
environments
• Make sure that the pump and the
electric connections are protected
from possible inundation
• Before using the pump, always
inspect it visually (especially power
cable and plug)
• Do not use the pump if it is damaged
• If the pump is damaged, have
it inspected by the specialised
assistance service only
• Do not transport the pump using the
cable or use the cable to remove the
plug from the socket
• Protect the plug and the power cable
from heat, oil or sharp edges
ELECTRICAL CONNECTIONS
CHAPTER 4
Verify that the voltage and frequency of the electropump shown on the nameplate correspond to those
available on the mains.
WARNING
The installer must make sure that the electric system is grounded in accordance with the law in force.
Make sure that the electric system has a high-sensitivity circuit breaker ∆=30 mA (DIN VDE 0100T739).
The power cable must be replaced by qualified personnel only.
DANGER - ELECTRIC SHOCK RISK
DANGER - ELECTRIC SHOCK RISK
DANGER - ELECTRIC SHOCK RISK
