peplink Pepwave MAX Transit User Manual

Port Type
Auto MDI/MDI-X ports
2.19 MAX MBX Mini
2.19.1 Panel Appearance
Note: For proper Wi-Fi performance and operations, please ensure all 4 Wi-Fi antenna
connectors (labeled Wi-Fi 1 and Wi-Fi 2) have antennas attached.
2.19.2 LED Indicators
The statuses indicated by the front panel LEDs are as follows:
LED Indicator
Power LED
OFF – Power off
GREEN – Power on
LAN Ports
Green LED
ON – POE Enabled
OFF - POE Disabled
Orange LED
Blinking – 10 / 100 / 1000 Mbps with activity
OFF – No data is being transferred or port is not connected
Port Type
Auto MDI/MDI-X ports
https://www.peplink.com
43
