F USE ALLOCATION
Satelis 125cc M2 Satelis 125cc M2 ABS/PBS-1 Satelis 1
25cc M3 Satelis 125cc M3 ABS/PBS-2
F1 30A
Regulator
Ignition switch
F1 30A
Regulator
Ignition switch
F1 30A
Regulator
Ignition switch
F1 30A
Regulator
Ignition switch
F2 10A
Injection ECU
Fuel pump relay
HT coil
Petrol injector
Immobiliser
Lambda sensor
Bypass valve
F2 30A
Relay ABS/PBS
Pressure control unit
F2 10A
Injection ECU
Fuel pump relay
HT coil
Petrol injector
Immobiliser
Lambda sensor
F2 30A Relay ABS/PBS
F3 10A
Accessory socket
Saddle opening module
a
F3 10A
Injection ECU
Fuel pump relay
HT coil
Immobiliser
Lambda sensor
Petrol injector
Bypass valve
F3 10A
Accessory socket
Saddle opening module
a
F3 10A
Injection ECU
Fuel pump relay
HT coil
Petrol injector
Immobiliser
Lambda sensor
F4 10A
Instrument panel
Lighting relay
F4 10A
Accessory socket
Saddle opening module
a
F4 10A
Instrument panel
Lighting relay
F4 10A
Accessory socket
Saddle opening module
a
F5 15A
Instrument panel
Motor-driven fan
Horn
"Side light" bulbs
Light flashing control
Number plate light. Rear light
Saddle opening module
a
Stop light switch
F5 15A
Instrument panel
Motor-driven fan
Horn
"Side light" bulbs
Light flashing control
Number plate light. Rear light
Saddle opening module
a
F5 15A
Instrument panel
Motor-driven fan
Horn
"Side light" bulbs
Light flashing control
Number plate light. Rear light
Saddle opening module
a
Stop light switch
F5 15A
Instrument panel
Motor-driven fan
Horn
Light flashing control
"Side light" bulbs
Number plate light. Rear light
Saddle opening module
a
Stop light switch
F6 5A
Injection ECU
Immobiliser
Diagnostic plug
Fuel pump relay
F6 5A
Injection ECU
Immobiliser
Diagnostic plug
Fuel pump relay
ABS/PBS diode
F6 5A
Injection ECU
Immobiliser
Diagnostic plug
Fuel pump relay
F6 5A
Injection ECU
Immobiliser
Diagnostic plug
Fuel pump relay
Pressure control unit
F7 10A
Instrument panel
Lighting relay
F7 10A
Instrument panel
Lighting relay
a. Depending on model
NOTICE_SATELIS-04D.mif Page 14 Vendredi, 26. mars 2010 2 :34 14

PEUGEOT satelis 125 Specifications

General

Transmission	Automatic CVT
Front Suspension	Telescopic fork
Front Tire	120/70-14
Rear Tire	140/60-13
Engine Type	4-stroke single cylinder
Fuel System	Electronic injection
Cooling System	Liquid
Front Brake	Disc brake
Rear Brake	Disc brake
