1:15
1:15
C
B
A
Operate your Pfaff select
Changing the needle
Switch off the main switch.
To remove: Lower the presser foot
and move the needle to its highest
point. Now loosen the needle
screw (18) and pull the needle
down.
To insert: The Á at side A of the
needle must face to the rear.
Lower the presser foot and insert
the needle, pushing it up as far
as it goes. Hold the needle and
tighten the needle screw (18)
À rmly.
Setting the needle thread tension
Set the required needle thread tension
(10) with the help of the mark B.
The normal setting for sewing is 4 to 5.
For free-motion sewing, darning and
buttonhole set the tension between 2 and
3.
Dropping the feed dog
For certain sewing work, e.g. darning or
free-motion sewing the feed dog has to be
dropped.
To do this, open the bobbin case/hook
cover and move slide C fully to the right.
Now the feed dog is dropped.
