8.12 715G8767 IR/LED (For 32” 4132&4032 Series)
8-12-1 IR & LED & Light Sensor
CN201
CONN
1
2
3
4
5
67
ZD202
NC/AZ5125-01H.R7G
12
C201
1uF 10V
Standby LED
3V3SB
R204
100R 1/16W 5%
R203
NC/2K7 1/16W 5%
RC-IR
3V3SB
LED201
GPSS008RC4
12
RC-IR
Red
ZD203
AZ5125-01H.R7G
12
ZD201
NC/AZ5125-01H.R7G
12
C202
1uF 10V
LED_R
Close to U201
IR Receiver
3V3SB
R202
22K 1/16W 5%
LED_R
Q201
BC847BW
R201
2K7 1/16W 5%
U201
TSOP75436TR
GND
1
VCC
2
Vout
3
GND
4
3V3SB
