Philips 43PFT4112/12 Service Manual

8.13 715G8623 IR/LED (For 43”/49” 4132 Series)
8-13-1 IR & LED & Light Sensor
IR_power
R227 NC/0R05 1/16W
R228 0R05 1/16W
R229 0R05 1/16W
RC-IR
C212
NC/1UF 6.3V
Standby LED
IR Receiver
3V3SB
RC-IR
3V3SB
LS_SCL
LS_SDA
DVD3V3
LED201
GPSS008RC4
12
Red
R201
10K 1/16W 5%
ZD202 NA/AZ5123-01H
1 2
DVD3V3
U221
JSA-1130
ADDR
1
VDD
2
GND
3
SCL
4
SDA
5
INT
6
R224
NC/0R05 1/16W
Light Sensor
Digital Light Sensor
R222
10K 1/16W 5%
R221
10K 1/16W 5%
C222 1uF 10V
LS_SDA
ZD203 NC/AZ5123-01H
1 2
R223 0R05 1/16W
JSA-1130
C221 100N 16V
LS_SCL
LS_SDA
R223 R224 R225 R226 R227 I2C ADDR
0x44NC 0R 0R NC NC
JSA-1130 0R NC 0R NC NC 0x45
TSL25715 0R NC NC 0R 0R 0x29
R228 R229
0R 0R
0R 0R
NC NC
DVD3V3
IR_power
U212
TSOP75436TR
GND
1
VCC
2
Vout
3
GND
4
CN201
NC/CONN
1
2
3
4
5
6
7
8
9
10 11
LED_R
R202
1K 1/16W 5%
RC-IR
3V3SB
LS_SCL
LS_SDA
DVD3V3
CN202
NC/CONN
1
2
3
4
5
6
7
8
9
10 11
LED_R
ZD200 ZD201 near U212 pin
ZD202 ZD203 near LED201
Q201
BC847BW
LED_R
CN203
CONN
1
2
3
4
5
67
LED_R
RC-IR
3V3SB
R225 0R05 1/16W
ZD200
AZ5123-01H
12
R226 NC/0R05 1/16W
LS_SCL
C211
1UF 6.3V
R211
100R 1/16W 5%
3V3SB
ZD201
AZ5123-01H
1 2
