Page #47 background imageLoading...
Page #47 background image
• Input level range : 25 to 65 dBm
• DVB-S/S2 QPSK, symbol rate 2 to 45M symbols,
SCPC and MCPC
• LNB : Unicable 1/2, DiSEqC 1.0, 1 to 4 LNBs
supported, Polarity selection 13/18V, Band selection
22kHz, Tone burst mode, LNB current 300mA max
19.5
Display Type
Diagonal screen size
• 108 cm / 43 inch
• 126 cm / 50 inch
• 139 cm / 55 inch
• 164 cm / 65 inch
Display resolution
• 3840 x 2160
19.6
Display Input Resolution
Supported Video only resolution
Resolution — Refresh rate
• 480i - 60 Hz
• 576i - 50 Hz
• 1080i - 50 Hz, 60 Hz
Supported Computer/Video resolution
Resolution — Refresh rate
• 640 x 480 - 60Hz
• 576p - 50Hz
• 720p - 50 Hz, 60 Hz
• 1920 x 1080p - 24 Hz, 25 Hz, 30 Hz, 50 Hz, 60 Hz
• 2560 x 1440 - 60 Hz
• 3840 x 2160p - 24 Hz, 25 Hz, 30 Hz, 50 Hz, 60 Hz
19.7
Connectivity
TV Side
• Common Interface slot: CI+/CAM
• USB 1: USB 2.0
• Headphones: Stereo mini-jack 3.5mm
• HDMI 1 in: ARC - Ultra HD - HDR
TV Bottom
• Digital Audio out: Optical
• USB 2: USB 2.0
• Network LAN: RJ45
• Satellite tuner
• Antenna (75 ohm)
• HDMI 2 in: Ultra HD - HDR
• HDMI 3 in: Ultra HD - HDR
• HDMI 4 in: Ultra HD - HDR
19.8
Sound
Output power (RMS) : 20W
Dolby MS12 V2.5
• Dolby Atmos
• DTS – HD (M6)
• Surround Virtualizer + Height Virtualizer
• Dolby Bass Enhancement
• Dolby Dialogue Enhancement
• Dolby Volume (AVL/Night Mode)
• AI Sound
19.9
Multimedia
Connections
• USB 2.0
• Ethernet LAN RJ-45
• Wi-Fi 802.11n Dual Band (built-in)
• BT 5.0
Supported USB file systems
• FAT 16, FAT 32, NTFS
Playback formats
• Containers: PS, TS, M2TS, TTS, AVCHD, MP4, M4V,
MKV, ASF, AVI, 3GP, Quicktime
• Video Codecs : AVI, MKV, HEVC, H264/MPEG-4
AVC, MPEG-1, MPEG-2, MPEG-4, VP9, HEVC (H.265),
AV1
• Audio Codecs : MP3, WAV, AAC, WMA (v2 up to
v9.2), WMA-PRO (v9 and v10)
• Subtitles :
– Formats : SRT, SMI, SSA, SUB, ASS, TXT
– Character encodings : UTF-8(Unicode), UTF-16,
Simplified Chinese, Central Europe, Cyrillic, Western
Europe, Greek, Turkish, Hebrew, Korean
• Maximum Supported Data Rate :
– MPEG-4 AVC (H.264) is supported up to High
Profile @ L5.1. 30Mbps
– H.265 (HEVC) is supported up to Main / Main 10
Profile up to Level 5.1 40Mbps
• Image Codecs : JPEG, GIF, PNG, BMP, HEIF
47
