Philips FR-984 User Manual

112
Nederlands
TECHNISCHE GEGEVENS
Wijzigingen voorbehouden zonder kennisgeving.
Algemeen
Stroomverbruik (FR 984, FR 985, FR 986)........................210 W
Stroomverbruik (FR 994, FR 995, FR 996)........................255 W
Stroomverbruik in stand-by ..............................................< 2 W
Afmetingen, b × h × d .............................435 × 135 × 350 mm
Gewicht (FR 984, FR 985, FR 986)....................................8,6 kg
Gewicht (FR 994, FR 995, FR 996)....................................9,4 kg
Versterkergedeelte (0,7 % THD, 6 Ω, 1 kHz)
Uitgangsvermogen, bij stereo
(FR 984, FR 985, FR 986) (DIN)....................................2 × 60 W
Uitgangsvermogen, bij surround (FR 984, FR 985, FR 986)
Voor.......................................................................2 × 60 W
Midden.........................................................................60 W
Surround................................................................2 × 60 W
Uitgangsvermogen, bij stereo
(FR 994, FR 995, FR 996) (DIN)..................................2 × 100 W
Uitgangsvermogen, bij surround (FR 994, FR 995, FR 996)
Voor.....................................................................2 × 100 W
Midden.......................................................................100 W
Surround..............................................................2 × 100 W
Lage tonen.......................................................±9 dB bij 100 Hz
Hoge tonen.......................................................±9 dB bij 10 kHz
Loudness...+6 dB bij 100 Hz (-30 dB); +3 dB bij 10 kHz (-30 dB)
Totale harmonische vervorming..............0,05 % bij 1 kHz, 5 W
Frequentiebereik.......................................20–20 000 Hz, ±1 dB
Signaal/ruis-verhouding ................................................≥ 82 dB
Kanaalscheiding (1 kHz).................................................≥ 45 dB
Overspraak (1 kHz)........................................................≤ -65 dB
Ingangen
Lijningangen .......................................................250 mV/47 kΩ
6 CH....................................................................250 mV/40 kΩ
Front AV (enkel FR 995, FR 996).........................250 mV/22 kΩ
Phono......................................................................5 mV/47 kΩ
Digitaal, coax..........................................75 Ω volgens IEC 958
Digitaal optisch................................................................Toslink
Digitale bemonsteringsfrequentie
(FR 984, FR 985, FR 986).....................32 kHz, 44,1 kHz, 48 kHz
Digitale bemonsteringsfrequentie
(FR 994, FR 995, FR 996)........32 kHz, 44,1 kHz, 48 kHz, 96 kHz
Uitgangen
Netuitgangen (geschakeld) ..........................totaal max. 100 W
Lijnuitgangen........................................................250 mV/1 kΩ
Digitaal coax...........................................75 Ω volgens IEC 958
Digitale uitgang-samplingfrequenties
Analoog in............................................................uit 48 kHz
Digitaal in 32 kHz.................................................uit 32 kHz
Digitaal in 44,1 kHz...........................................uit 44,1 kHz
Digitaal in 48 kHz.................................................uit 48 kHz
Digitaal in 96 kHz
(enkel bij FR 994, FR 995, FR 996).......................uit 48 kHz
Subwoofer pre-out....................................................0,8 V/1 kΩ
Center pre-out...........................................................0,8 V/1 kΩ
Hoofdtelefoon.................................8–600 Ω (3 V e.m.f., 60 Ω)
Luidsprekers......................................................................≥ 6 Ω
Tuner
Golfbereik
FM..............................................................87,5–108,0 MHz
MW...............................................................531–1 602 kHz
LW....................................................................153–279 kHz
Gevoeligheid
Stereo FM..................................................................41 dBf
Mono FM....................................................................15 dBf
Totale harmonische vervorming
Stereo FM...................................................................0,3 %
Mono FM...................................................................0,85 %
Frequentiebereik........................................63–12 500 Hz ±1 dB
Signaal/ruis-verhouding
Stereo FM....................................................................55 dB
Mono FM.....................................................................60 dB
Kanaalscheiding.................................................35 dB bij 1 kHz
Receiver
