Philips PET726 User Manual

1.0 TECHNICAL SPECIFICATION
General
Dimensions (W x H x D): 158 x 210 x 39.5 mm
Bear Unit Weight: 0.79 kg +/- 5%
Power supply:
Supply voltage Input: 100~240V + / - 10%
50/60Hz 0.3A
Output: DC 9V 1A
Supply Power
consumption (AC adaptor
100/240VAC)
9W + 10%
Operating Temperature 0 – 45degC
Video System NTSC / PAL
Frequency response 20-20kHz +/-1dB
THD 20-20kHz (%): </=3%
Dynamic range 1kHz >/=80dB
Signal/Noise ratio: >/=80dB
Channel Separation 1kHz >=80dB
Channel Balance 1kHz <2dB
Current consumption
Playback time
Capacity--- Refer to battery
spec
≥
1600mAH
Battery discharge cut-off
current
40mA
Max.battery charge
current(continue charge) of
DCP850 & DCP750
400-500
Charging time 2 +/- 0.5H
Headphone out (headphone output load 2x16 ohm)
Maximum output power:
1.5mW
Frequency response:
+/-3dB
SNR (A-wght):
>70dB
THD (0.2-20kHz):
3%
Left-Right Channel
Separation:
>/=50dB
Left-Right Channel
Balance:
</=1dB
Supported disc type
Video Playback
Formats:
Audio Playback
Formats:
Playback disc type: DVD, Picture-CD,
SVCD, Video CD, MP3-
CD, CD-R/CD-RW,
WMA-CD, DVD-R, DVD-
RW, DVD+R, DVD+RW
Video Playback Format: DVD / VCD / SVCD / CD
/ JPEG
Audio Playback Format: CD/MP3, MP3-DVD,
DVD
Disc Diameter 12cm
Pixel specification
Max. 0 bright-dot & max. 3 dark-dots
Factory Service Mode (FSM)
To check the software version and change
region code of your DVD Portable
1. Power ON the DVD player and open the DVD
door
2. Press the “SETUP” button on remote control,
then select the “Preference MENU”
3. Press the remote button in the sequence as
9 -> 6 -> 5 -> 3
4. The LCD display showed the existing region
code. Press (navigation up) or
(navigation down) repeatedly to select the
number from 0 to 6.
5.
Refer below table for your region code setting
Select “0” setting = Region Free (confidential)

Philips PET726 Specifications

Picture/Display

display screen type	LCD TFT
diagonal screen size	7 inch
brightness	200 cd/m²
resolution	480(w)x234(H)x3(RGB)
contrast ratio	250:1
effective viewing area	154.1x86.6mm

Sound

output power (built-in speakers)	250mW RMS
output power (earphone)	10mW RMS
signal to noise ratio (line out)	>80dB
signal to noise ratio (earphone)	76dB
signal to noise ratio (built-in speakers)	>62dB

Connectivity

DC in	9~12V
headphone jack	3.5mm Stereo Headphone
AV output	Composite (CVBS) x1

Accessories

AC/DC adaptor	9V (110-240v, 50/60Hz)
car kit	cigarette outlet adaptor, 12vDC
second LCD screen	7" TFT LCD x 1 pcs

Dimensions

product dimensions (W x H x D)	210 x 158 x 39.5 mm
product weight	0.79 kg
master carton dimensions	255 x 308 x 350 mm
master carton weight	7.65 kg
packaging dimensions (W x H x D)	345 x 295 x 78 mm
