Phonic POWERPOD 620 plus v1 User Manual

Phonic Part No. Specications Ref.
22
POWERPOD 620 V1
PL US
POWER PCB-PART LIST(10202001T020G)
000104710000G CF RES. 100 J 1/2W T26mm R88
000103710010G CF RES. 1K J 0.25W T R76.93.105,105B
000105751020G CF RES. 51K J 1W R82.78
003029712070G CEMENT RES. 12 ohm 5W VERTICAL
R100
000103710070G CF RES. 10 J 0.25W T R52B
000103718000G CF RES. 180 J 1/4W T26mm R86
003029727000G CEMENT RES. 270 5W VERTICAL R99
000103718010G CF RES. 1K8 J 0.25W T R80
000103720030G CF RES. 200K J 0.25W T R83
005006715020G MOF RES. 15K J 2W M
R101
000103722070G CF RES. 22 J 0.25W T R87
005006747070G MOF RES. 47J 2W +/-5% R91.92
000103733080G CF RES. 3.3 J 1/4W T26mm R90.108
005007768000G MOF RES. 680 J 3W P R90B.108B
000103747000G CF RES. 470 J 1/4W T R84
006104547030G MF RES. 470K F 1/2W T26mm R77
000103747020G CF RES. 47K J 0.25W T R102
00A000950081G NTC NTD04-005 5(YONGZHEN)15mm 5R
NTC1
000103751010G CF RES. 5K1 J 0.25W T R103
00C251050001G R/V 500ohm 0.5W 3P AL SVR3
000103751070G CF RES. 51 J 1/4W T26mm R89
000103762000G CF RES. 620 J 0.25W T R109
01003C206870G E/C 680uF M 200V 25*36 P C56.58
000103768000G CF RES. 680 J 0.25W T R85
000103768010G CF RES. 6K8 J 0.25W T R107
01033B104760G E/C 47uF K 160V 13*21 T C78
006103524020G MF RES. 24K F 1/4W T26mm R75
01J00H201020G LINE/C 0.001uF M 400V Y1 C68
010334201070G E/C 100uF M 35V 8*12 T C54
01J22D202220G LINE/C 0.0022uF M 250VAC Y2 C55.50
010335204760G E/C 47uF M 50V 8*11 T C81.45B
01J22E102240G LINE/C 0.22uF K 275V P C51.52
010336004760G E/C 47uF J 63V 6*12 T C76.79.80
020033003500G
COIL (THREE LAYERS INSULATION) T4
017305401040G ML/C 0.1MF Z 50V 5 C59.65.66
020033003700G EI XMER 120V
T1
01930L101010G C/C2 100pF K 1000V 5T C67
020033003800G EI COIL. RG160/260 T2
01930L104710G C/C2 470pF K 1000V 5T C74.75
020033007500G XMER EMX2060S HIGH FREQUENCY
TRANSFORMER EE-4
T3
