Phonic POWERPOD 620 plus v1 User Manual

Phonic Part No. Specications Ref.
27
POWERPOD 620 V1
PL US
00C111050020G T/VR 50K 0.1W D8 3M S TVR801.802
000102710010G CF RES. 1K J 1/8W T R334.434,840.841,845
00D00G020022G S.ROT/VR. 20KB 30MM P FUHUA VR104.204,304.404,504.604,
801
000102710020G CF RES. 10K J 1/8W T R532.533,536.632,633.636,820
.842,843.844,856
00D00G020028G S.ROT/VR 20KA L=30MM F=12MM VR103.105,203.205,303.305,40
3.405,503.505,603.605,
803.804,807.808
000102710030G CF RES. 100K J 1/8W T R101.134,135.201,234.235,301
.401,501.601,822.828,
829.836,876
00D00G050028G S.ROT/VR. 50KB(C.C) 30MM FUGUI VR101.102,201.202,301.302,40
1.402,501.502,601.602
000102710040G CF RES. 1M J 1/8W T26mm R333.433
00J001220020G D.SLD/VR. 20KW*2 20MM P FUHUA VR901-907
000102710070G CF RES. 10 J 1/8W T R106.107,110.111,128.206,207.
210,211.228,306.307,
310.311,328.406,407.410,411.4
28,R506.507,510.511,
528.606,607.610,611.628
01J22D106830G LINE/C 0.068uF K 250V SQUARE
C1
000102711010G CF RES. 1K1 J 1/8W T R911.912,915.916,919.920,923
.924,927.928,931.932,935.936
067001000100G LED BL-B5141 RED BAIHONG LED802.808,813
000102712020G CF RES. 12K J 1/8W T R801.802,874
067001000900G LED L-704ID RED JINTAI 3*3 SQUARE LED2
000102712030G CF RES. 120K J 1/8W T26mm R803.804,805.875,877
067004000000G LED BL-B3141 YLW BAIHONG LED806.807,811.812
000102715000G CF RES.150 J 1/8W T R112.212,312.412,512.612
067005000100G LED BL-B2141 GRN BAIHONG LED804.805,809.810
000102718010G CF RES. 1K8 J 1/8W T R846
067007000000G LED 204UBD D3 BLUE YIGUANG LED801
000102718020G CF RES. 18K J 1/8W T R513.538,613.638,857
067024000300G LED L-740YD YLW 3*3 SQUARE
LED1
000102722000G CF RES. 220 J 1/8W T26mm R813.814
080000001200G IC AN6884 DIP (MA) IC810.811
000102722010G CF RES. 2K2 J 1/8W T R806.807
080000010100G IC TL074CN DIP(TI/ST) U901-904
000102722020G CF RES. 22K J 1/8W T R335.435,808.809,873.
080001007000G IC NJM4580L DIP(JRC) IC801-805,807,101-108
MASTER PCB-PART LIST(10202001A020G)
