Proceed to fit the specific roller bearing (3) using the specific punch (2). Once this operation is com-
pleted, fit the sealing ring (1).
N.B.
BEFORE FITTING THE ROLLER BEARINGS, ALWAYS REFER TO THE STANDARDS LISTED IN
THE TABLE "TIGHTENING TORQUE".
Specific tooling
19.1.20044 Front wheel hub roller bearing fitting punch
BALL BEARING - CIRCLIPS ON THE FRONT BRAKE DRUM - FITTING
Heat, with the specific tool, the bearing housing area and fit with the specific punch (5), the relative ball
bearing (6).
Complete the fitting with the insertion, using the special tool, of the circlip (4).
WARNING
BEFORE REFITTING THE DRUM, FILL THE INTERNAL CHAMBER WITH THE SPECIFIC GREASE.
Recommended products
AGIP GREASE PV 2 Multipurpose grease
NLGI 2 specifications; ISO-LXBIB2
APE TM Benzina Suspensions
SS - 117
