VEHICLE TECHNICAL DATA
Chassis Stamped plate supporting body.
Front suspension Single arm suspension (cantilever
wheel) fitted with a dual-chamber
hydraulic shock absorber with
coaxial spring.
Rear suspension Two double-acting shock
absorbers, adjustable to four
positions at pre-loading.
Front brake Ø 220 mm hydraulically operated
disc brake controlled from RH
handlebar lever; braking assisted
by ABS system.
Rear brake Ø 220 mm hydraulically operated
disc brake controlled from LH
handlebar lever; braking assisted
by ABS system.
Wheel rim type Light alloy.
Front rim 12'' x 3.00
Rear rim 12'' x 3.00
Front tire 120/70 - 12'' 51P Tubeless
Rear tire Tubeless 130/70 - 12'' 62P
Front tire pressure (with
passenger)
1.8 bar (1.8 bar)
Rear tire pressure (with
passenger)
2.0 bar (2.2 bar)
Kerb mass 160 kg
87
