Pioneer A-105 User Manual

OF
iONE
IONE
iONE
|ONE
ONE
I6B0
a20v 2aov
ov 120127¥
VOLTAGE SELECTOR
|
2
<ARE7O74>
En
Thank you for buying this Pioneer product.
Please read through these operating instructions so you wil]
know how to operate your model properly. After you have
finished reading the instructions, put them away in a safe place
for future reference.
in some countries or regions, the shape of the power plug and
power outlet may sometimes differ from that shown in the
explanatory drawings. However, the methad of connecting and
operating the unit is the same.
(——
CONTENTS -
FEATURES
INSTALLATION,
PANEL FACILITIES
CONNECTIONS
OPERATIONS.
TROUBLESHOOTING
SPECIFICATIONS
___
FEATURES
e@High power output
Model A-105
Model A-205
. 30 W + 30 W/8 2 (DIN)
. 55 W + 55 W/4 22 (DIN)
45 W + 45 W/8Q (DIN)
Wide-Range Linear Circuit
This new current feedback circuit assures improved operating
stability for flat output impedance and stable driving of speakers
across the full range of frequencies.
e@The use of a DIRECT circuit ensures high fidelity playback of
consistent frequency characteristics, with maximum clarity,
@ Bi-directional dubbing is possible by using two cassette decks.
e@ Speaker terminals for two speaker systems are provided. {A-
205 only)
LINE VOLTAGE SELECTOR SWITCH
Only multi-voltage model is provided with this switch. Round
2-pin AC plug model is not provided with this switch.
Main voltages in Saudi Arabia are 127 V and 220 V only. Never
use this model with 110 V setting in Saudi Arabia.
The line voltage selector switch is on the rear panel, Check that
it is set properly before plugging the power cord into the AC-wall
socket. If the voltage is not properly set or if you move to an area
where the voltage requirements differ, adjust the selector switch |
as follows:
1. Use a medium-size screwdriver.
2. Insert the screwdriver into the groove on the voltage selector,
and adjust so that the tip of the arrow points to the voltagé
value of your area.
