Specifications (VSX-D514)
Amplifier Section
Continuous average power output of 100 watts*
per channel, min., at 8 ohms, from 20 Hz to
20,000 Hz with no more than 0.2 %** total
harmonic distortion (front).
Continuous Power Output (Stereo)
Front ........................................................... 100 W
(20–20,000 Hz, THD 0.2 %, 8 Ω)
Continuous Power Output (Surround)
Front ...................................... 100 W per channel
(1kHz, THD 1.0 %, 8 Ω)
Center .................. 100 W (1kHz, THD 1.0 %, 8 Ω)
Surround ............................... 100 W per channel
(1kHz, THD 1.0 %, 8 Ω)
Input (Sensitivity/Impedance)
CD, DVR/VCR, CD-R/TAPE/MD,
DVD/LD, TV/SAT ........................... 200 mV/47 kΩ
Frequency Response
CD, DVR/VCR, CD-R/TAPE/MD, DVD/LD,
TV/SAT ........................... 5 Hz to 100,000 Hz dB
Output (Level/Impedance)
DVR/VCR REC, CD-R/TAPE/MD REC
...................................................... 200 mV/2.2 kΩ
Tone Control
BASS .......................................... ± 6 dB (100 Hz)
TREBLE ...................................... ± 6 dB (10 kHz)
LOUDNESS .... +6.5 dB/+3 dB (100 Hz/10 kHz)
(at volume level –50 dB)
Signal-to-Noise Ratio
(IHF, short circuited, A network)
CD, DVR/VCR, CD-R/TAPE/MD,
DVD/LD, TV/SAT ......................................... 96 dB
Signal-to Noise Ratio
[EIA, at 1 W (1 kHz)]
CD, DVR/VCR, CD-R/TAPE/MD,
DVD/LD, TV/SAT ......................................... 79 dB
Video Section
Input (Sensitivity/Impedance)
DVR/VCR, DVD/LD, TV/SAT ............. 1 Vp-p/75 Ω
Output (Level/Impedance)
DVR/VCR ........................................... 1 Vp-p/75 Ω
Frequency Response
DVR/VCR, DVD/LD,
TV/SAT ] MONITOR........... 5 Hz to 7 MHz dB
Signal-to-Noise Ratio ................................. 55 dB
Cross Talk .................................................... 55 dB
FM Tuner Section
Frequency Range ............. 87.5 MHz to 108 MHz
Usable Sensitivity ................ Mono:13.2 dBf, IHF
(1.3 µV/ 75 Ω)
50 dB Quieting Sensitivity .......... Mono: 20.2 dB
Stereo: 38.6 dBf
Signal-to-Noise Ratio ..................... Mono: 73 dB
(at 85 dBf)
Stereo: 70 dB (at 85 dBf)
Distortion ........................... Stereo: 0.5 % (1 kHz)
Alternate Channel Selectivity .................... 60 dB
(400 kHz)
Stereo Separation ......................... 40 dB (1 kHz)
Frequency Response .................. 30 Hz to 15 kHz
(±1 dB)
Antenna Input (DIN) .............. 75 Ω unbalanced
AM Tuner Section
Frequency Range .............. 530 kHz to 1,700 kHz
Sensitivity (IHF, Loop antenna) ............ 350 µV/m
Signal-to-Noise Ratio ................................. 50 dB
Antenna ........................................ Loop antenna
+0
– 3
+0
– 3
