5. ELECTRICAL PARTS LIST
NOTES:
- Parts whose parts numbers are omitted are subject to being not supplied.
- The part numbers shown below indicate chip components.
Chip Resistor
RS1/_S___J,RS1/__S___J
Chip Capacitor (except for CQS.....)
CKS....., CCS....., CSZS.....
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
Unit Number : CWM7292
Unit Name : Tuner Amp Unit
MISCELLANEOUS
IC 301 IC PML003AM
IC 302 IC PAL006A
IC 601 IC PE5196A
IC 602 IC S-80834ANY
Q 346 Transistor RN1610
Q 350 Transistor DTA124EK
Q 351 Transistor DTC114EK
Q 353 Transistor DTA124EK
Q 411 Transistor 2SC2412K
Q 650 Transistor 2SA1037K
Q 901 Transistor 2SC2412K
Q 902 Transistor 2SC2412K
Q 903 Transistor 2SD1859
Q 904 Transistor 2SD2396
Q 905 Transistor 2SB1243
Q 906 Transistor DTC114EK
Q 920 Transistor RN46A1
Q 981 Transistor 2SD2396
Q 982 Transistor RN46A1
D 650 Diode 1SS270
D 651 Diode 1SS270
D 652 Diode 1SS270
D 653 Diode 1SS270
D 654 Diode 1SS270
D 655 Diode 1SS270
D 901 Diode HZS7L(C2)
D 902 Diode S5688G
D 903 Diode S5688G
D 904 Diode HZS7L(A1)
D 905 Diode S5688G
D 906 Diode HZS6L(B2)
D 907 Diode HZS9L(B3)
D 941 Diode S5688G
D 942 Diode S5688G
D 981 Diode HZS9L(B1)
L 310 Ferri-Inductor LAU1R0M
L 401 Ferri-Inductor LAU4R7K
L 402 Ferri-Inductor LAU2R2K
L 403 Inductor LAU100K
L 610 Ferri-Inductor LAU101K
L 611 Ferri-Inductor LAU2R2K
L 650 Ferri-Inductor LAU2R2K
L 901 Choke Coil 600µH CTH1221
X 610 Crystal Resonator 4.194304MHz CSS1023
AR 946 Arrester DSP-201M-S00B
FM/AM Tuner Unit CWE1563
RESISTORS
R 310 RD1/4PU222J
R 311 RD1/4PU222J
R 332 RS1/16S221J
R 333 RS1/16S221J
R 334 RS1/16S221J
R 335 RS1/16S221J
R 342 RS1/16S681J
R 343 RS1/16S681J
R 344 RS1/16S223J
R 345 RS1/16S223J
R 346 RS1/16S0R0J
R 351 RS1/16S102J
R 352 RS1/16S103J
R 353 RS1/16S103J
R 354 RS1/16S331J
R 360 RD1/4PU153J
R 411 RS1/16S681J
R 412 RS1/16S681J
R 413 RS1/16S681J
R 414 RS1/16S103J
R 415 RS1/16S681J
R 416 RD1/4PU473J
R 417 RD1/4PU472J
R 418 RS1/16S473J
R 419 RS1/16S473J
R 420 RS1/16S473J
R 421 RS1/16S473J
R 422 RS1/16S473J
R 423 RS1/16S681J
R 424 RS1/16S681J
R 425 RS1/16S393J
R 427 RS1/16S222J
R 428 RS1/16S222J
R 460 RS1/16S272J
R 461 RS1/16S272J
R 464 RS1/16S162J
R 465 RS1/16S162J
R 468 RS1/16S0R0J
R 469 RS1/16S0R0J
R 610 RD1/4PU822J
R 611 RS1/16S473J
R 619 RS1/16S0R0J
R 620 RS1/16S223J
R 622 RD1/4PU222J
R 623 RD1/4PU222J
R 624 RS1/16S473J
R 625 RS1/16S473J
R 626 RS1/16S473J
R 627 RS1/16S473J
R 628 RD1/4PU222J
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
