38
DEH-3130R,3100R-B,3100R
5. ELECTRICAL PARTS LIST
NOTES:
- Parts whose parts numbers are omitted are subject to being not supplied.
- The part numbers shown below indicate chip components.
Chip Resistor
RS1/_S___J,RS1/__S___J
Chip Capacitor (except for CQS.....)
CKS....., CCS....., CSZS.....
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
Unit Number : CWM6841
Unit Name : Tuner Amp Unit
MISCELLANEOUS
IC 451 IC PML003AM
IC 551 IC PAL005A
IC 601 IC PE5139A
IC 631 IC S-80734AN
IC 701 IC PM4009A
Q 431 Transistor IMH3A
Q 434 Transistor DTA124EU
Q 502 Transistor 2SC4081
Q 507 Transistor DTA124EU
Q 524 Transistor IMH3A
Q 525 Transistor DTA114ES
Q 540 Transistor 2SC1740S
Q 541 Transistor 2SD1757K
Q 542 Transistor 2SD1757K
Q 551 Transistor DTC144ES
Q 601 Transistor DTA114ES
Q 651 Transistor 2SA933S
Q 652 Transistor 2SB1236
Q 653 Transistor DTC124ES
Q 701 Transistor DTA124ES
Q 921 Transistor 2SA1576
Q 971 Transistor IMX1
Q 973 Transistor 2SD1859
Q 981 Transistor 2SD2396
Q 982 Transistor IMD2A
Q 991 Transistor 2SD2396
Q 992 Transistor IMD2A
D 651 Diode MTZ5R6J(C)
D 654 Diode Network DA204U
D 655 Diode Network DA204U
D 656 Diode Network DA204U
D 921 Diode DAN202U
D 931 Diode ERA15-02VH
D 932 Diode ERA15-02VH
D 951 Diode ERA15-02VH
D 952 Diode ERA15-02VH
D 971 Diode HZS7L(C2)
D 972 Diode HZS6L(C3)
D 973 Diode ERA15-02VH
D 974 Diode HZS6L(B1)
D 981 Diode HZS9L(B3)
D 992 Diode HZS9L(B1)
L 501 Ferri-Inductor LAU4R7K
L 504 Ferri-Inductor LAU2R2K
L 506 Inductor LAU100K
L 601 Inductor LAU100K
L 619 Ferri-Inductor LAU2R2K
L 621 Ferri-Inductor LAU2R2K
L 651 Ferri-Inductor LAU101K
L 701 Ferri-Inductor LAU101K
L 702 Inductor LAU100K
L 921 Ferri-Inductor LAU2R2K
L 951 Choke Coil 600µH CTH1221
TH 601 Thermistor CCX1031
X 601 Radiator 12.58291MHz CSS1402
X 701 Crystal Resonator 3.648MHz CSS1447
FM/AM Tuner Unit CWE1500
BZ 601 Buzzer CPV1050
AR 501 DSP-201M-S00B
RESISTORS
R 421 RS1/10S473J
R 431 RS1/10S821J
R 432 RS1/10S821J
R 437 RS1/10S223J
R 438 RS1/10S223J
R 443 RS1/10S0R0J
R 445 RS1/8S473J
R 465 RD1/4PU221J
R 466 RD1/4PU221J
R 502 RD1/4PU222J
R 503 RS1/10S222J
R 508 RS1/10S681J
R 509 RS1/10S473J
R 510 RS1/10S681J
R 511 RS1/10S473J
R 512 RS1/10S681J
R 513 RS1/8S473J
R 514 RS1/10S681J
R 515 RS1/8S473J
R 516 RS1/10S681J
R 517 RS1/8S472J
R 518 RS1/10S103J
R 519 RS1/10S393J
R 520 RS1/10S681J
R 521 RS1/10S473J
R 522 RD1/4PU681J
R 523 RS1/10S473J
R 526 RS1/10S104J
R 527 RS1/10S104J
R 528 RD1/4PU102J
R 530 RS1/10S681J
R 531 RS1/10S473J
R 532 RD1/4PU681J
R 533 RS1/10S473J
R 534 RS1/10S162J
R 535 RS1/10S162J
R 536 RS1/10S272J
R 537 RS1/10S272J
R 540 RS1/10S224J
R 541 RS1/10S224J
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
