Changing the settings
1
1
Setup item button
1 Press [LIVE SAMPLER (UTILITY, WAKE UP)] for at least 1
seconds.
The [USER SETUP] screen appears.
The [LIVE SAMPLER (UTILITY, WAKE UP)] indicator flashes.
! To display the [CLUB SETUP] screen, first turn this unit’s power off, then press
[POWER] while pressing [LIVE SAMPLER (UTILITY, WAKE UP)].
2 Press the setup item button.
The selection items appear.
3 Select the setup item.
Select the item on the touch panel and enter it.
4 Change the item’s setting.
Select the item on the touch panel and enter it.
! Press [SAVE] to save the changes to the [CLUB SETUP] screen.
5 Press [EXIT].
The [USER SETUP] screen closes.
! To close the [CLUB SETUP] screen, press [POWER] to turn this unit’s power
off.
Setting preferences
Settings indicated in italics are the default settings set upon purchase.
Mode Options settings Selection item 1 Selection item 2 Selection item 3 Descriptions
USER SETUP
MIDI
ZONE1
1
BUTTON ACTION
TOGGLE
Select the MIDI signal sending method, [TOGGLE] or [TRIGGER].
TRIGGER
MIDI CHANNEL
1, 2, to 16 Sets the MIDI channel.
ZONE2
2
BUTTON ACTION
TOGGLE
Select the MIDI signal sending method, [TOGGLE] or [TRIGGER].
TRIGGER
MIDI CHANNEL
1, 2, to 16 Sets the MIDI channel.
RESET
—
Restores the [TYPE A] – [TYPE D] MIDI settings to the default values.
[RESET] function is unique to [ZONE2].
FADER START
LINK
CH1 to CH4 ON, OFF
Turns the fader start function of the DJ players connected to the
[LINK] terminals on and off.
CONTROL
CH2, CH3 ON, OFF
Turns the fader start function of the DJ players connected to the
[CONTROL] terminals on and off.
LCD BACK LIGHT
1, 2, 3, 4, 5 — Adjusts the touch panel’s brightness.
VERSION No.
— — — Displays the DJM-2000’s software version.
CLUB SETUP
SYSTEM
DIGITAL OUT MAX
LEVEL
–19 dB, –15 dB, –10 dB,
–5 dB
—
Adjusts the maximum audio level output from the [DIGITAL OUT]
terminal.
DIGITAL SAMPLING
RATE
48 kHz, 96 kHz — Switches the digital signal sampling rate.
AUTO STANDBY
ON, OFF — Turns the auto standby function on and off.
MIC
OUTPUT TO BOOTH
MONITOR
ON, OFF —
Sets whether or not to output the microphone’s audio signals from
[BOOTH] terminals.
TALK OVER THRESH-
OLD LEVEL
–25 dB, –20 dB, –15 dB,
–10 dB
—
Sets the talkover sensitivity. The talkover function is activated when
a sound with a volume above the set volume is input to the micro-
phone.
TALK OVER LEVEL
–25 dB, –20 dB, –15 dB,
–10 dB
—
Sets the attenuation level for the sound other than the microphone’s
sound when the talkover function is activated.
TOUCH PANEL
— — — The touch panel’s calibration is adjusted by pressing [+] in order.
FACTORY RESET
YES, NO — — Restores all the settings to their factory defaults.
1 Changes the MIDI settings of the buttons on the control panel, [FREQUENCY MIX] and [SIDECHAIN REMIX].
2 Changes the MIDI settings for [TYPE A] to [TYPE D] on the MIDI control screen.
About the auto standby function
When [AUTO STANDBY] is set to [ON], the standby mode is set automatically if 4 hours pass with all of the conditions below met.
— That none of this unit’s buttons or controls are operated.
— That no audio signals of –10 dB or greater are input to this unit’s input terminals.
— That no PRO DJ LINK connections are made.
! The standby mode is canceled when [LIVE SAMPLER (UTILITY, WAKE UP)] is pressed.

Pioneer DJM-2000 Specifications

General

Sample rate	96 kHz
Frequency range	20 - 20000 Hz
Channels quantity	4 channels
Digital sound processing	32 bit
Number of EQ bands per channel	3
Line Signal-to-Noise Ratio (SNR)	107 dB
Total Harmonic Distortion (THD)	0.004 %
MIDI out	Yes
Line inputs (RCA)	6
Phono inputs (RCA)	2
USB 2.0 ports quantity	1
Dimensions (WxDxH)	430 x 107.9 x 409 mm
Power consumption (typical)	40 W

Weight and Dimensions

Weight	8500 g
