(1) AMP SECTION PARTS LIST
(2) CONTRAST TABLE
S-RS3SW/WDLPWXJ and S-RS3SW/LFXJ are constructed the same except for the following:
Mark No. Description Part No.
1 AMP Assy XWZ4360
2 JACK Assy XWZ4351
3 REGULATOR Assy XWZ4358
> 4 TRANS Assy XWM3442
5 FAN Assy XWZ4359
> 6 PSW Trans See Contrast table (2)
> 7Fuse See Contrast table (2)
> 8 AC Inlet Cable Assy XDX3077
> 9Cable Assy XDX3078
> 10 DC FAN Motor XXM3012
NSP 11 Chassis PSW (MTL) XNA3066
12 Cord Bracket Inl XNG3187
13 H/S Bracket L XNG3188
14 H/S Bracket R XNG3189
15 REG Bracket XNG3190
NSP 16 H/Sink PSW (MTL) XNH3051
17 • • • • •
18 Wire Saddle (PLS) AEC7586
19 Washer Cushion XEB3074
20 • • • • •
21 PSW Encoder GND XNK3026
NSP 22 Binder (BK-1) ZCA-BK1
23 MIC Knob (PLS) XAA3029
24 R/Cover PSW 1 Type XMC3005
NSP 25 SBOX PSW360x425x300 XXG3388
NSP 26 Fuse Card See Contrast table (2)
27 Screw BBZ40P080FNI
28 Screw BPZ30P080FTB
29 Screw (M3) XBA3019
30 Screw BBZ30P060FTC
31 Screw BBZ30P080FNI
32 Screw BBZ30P140FTC
NSP 33 Rear Cover Cush (Rub) XEB3129
NSP 34 Fan Cushion (Rub) XEB3139
NSP 35 Trans Cushion XEB3134
NSP 36 AMP Assy Cush (Rub) XEB3138
Mark
No. Description Part No.
Mark No. Symbol and Description S-RS3SW/WDLPWXJ S-RS3SW/LFXJ
>
6 PSW Trans XTS3115 XTS3116
>
7Fuse REK1024 REK1027
(T1.6 AL250 V) (T3.15 AL250 V)
NSP
26 Fuse Card Not used AAX7493
