Remove the
evap
orator
ass
embly
12 Remove
the
centrifugal
fan
1)
Remove the
electronic
control box
Repeat the operation of No.2 to remove the electronic control
box
2) Remove the air
outlet grille
ass
embly
Repeat the operation of No.7 to remove the air outlet grille
assembly
3) Remove four
fixing
screws to
remove
the
v
entilation
assembly
4) Remove the hex
nut fixing the
fan to remov
e
the
fan.
13 Remove
the fan
motor
1)
Remove the
centrifugal fan
Repeat the operation of No.12 to remove the centrifugal fan
2) Remove the fan
mo
tor after
unfastening
three fixing
screws.
3 screws
Each side has two screws
